Soundproofing Sliding movable doors

$89.99 - 129.99 /Square Meter
Sound-absorbing board varieties:
Share:
  • Product Description
Overview
Product Attributes

Model No.MQ-PARTITION

BrandMAGIC CUBE

Warranty Service5 Years

After-sales ServiceOnline Technical Support, Return And Replacement, Other

Engineering Solution CapabilityTotal Solution For Projects, Others

Application ScenarioHotel, Office Building, Workshop, Mall, Gym, Home Office

Design StyleContemporary, Farmhouse, Rustic, Mid-Century Modern, Chinese, Traditional, Scandinavian, European, French, Modern, Postmodern, Asian, Transitional, Minimalist, Eclectic, Tropical, Mediterranean, Southwestern, Victorian, Industrial, Coastal, Craftsman, Japanese, Midcentury

Place Of OriginChina

Model NO.Movable Partitions

TypeMelamine MDF Panel, Fireproof PVC Board, Fabric

ApplicationOffice, Hotel Banquet Hall, etc.

Main MaterialAluminum Frame and Track

Soundproof MaterRock Rool , Glass Wool

Soundproof Stc40dB-50dB

DimensionsW700-1200mm, H2000-5200mm, Thickness 80-110mm

Stacking WayCentre Partiting; Side Parking

Open WaySliding Partition

Ransport PackageCarton Paper Packaging, MDF Batten Cover Corners

Supply Ability & Additional Information

PackagingCarton Paper Packaging, MDF Batten Cover Corners

Productivity5000sq/Month

TransportationOcean

Place of OriginCHINA

Supply Ability5000sq/Month

CertificateCE

HS Code76101000

PortSHENZHEN,GUANGZHOU

Payment TypeT/T,Others

IncotermFOB,CIF,EXW

Packaging & Delivery
Selling Units:
Square Meter
Package Type:
Carton Paper Packaging, MDF Batten Cover Corners
Product Description




Acoustic Panels are widely used for installation in various places, such as different places, different places, etc. , you need to know in detail the height and length of the customer at any location and the needs of the Acoustic Panels to design the installation plan of the partition wall size. The biggest feature of the movable partition wall is that it can be freely recombined into the required space. Most likely the installation was successful.



Specifications

Type 65 type, 80 type, 100 type, ultra high 100 type.
Finish melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel
Density  28~32kg/m²
STC 40db-50db
Dimensions width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg
Structure 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing


Product Structure


Eco Friendly Soundproof Automatic Room Dividers Movable Partition Wall for Multi-Function Hall
Eco Friendly Soundproof Automatic Room Dividers Movable Partition Wall for Multi-Function Hall



Panel Suspension  Top hunge system without the need for a floor track.
Panel Width Each panel 600mm-1200mm.
Track Aluminum OR Steel Track
Roller on panel Single or double  roller.
Panel Frames  Heavy-duty steel-gusseted aluminum inner frames reinforced with  full height.
Top&bottm seals Top and bottom pressure retractable seals ensure effortless moved and locked.
Module 700mm - 1200mm maximum.
Panel stacking Numerous panel stacking options for complete flexibility.
Panel face  MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard




Eco Friendly Soundproof Automatic Room Dividers Movable Partition Wall for Multi-Function Hall

Ultra high 100 type

    Ultra-high Movable Partition is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high partition can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.

Features

  • Load bearing of each meter is more than 2000 KGS
  • Each pulley bearing more than 1500 KGS
  • Easily moved even being pushed at waist-high
  • The panel can make a turn automatically as sliding in the straight rail


Eco Friendly Soundproof Automatic Room Dividers Movable Partition Wall for Multi-Function Hall

Eco Friendly Soundproof Automatic Room Dividers Movable Partition Wall for Multi-Function Hall

Stacking Ways

Eco Friendly Soundproof Automatic Room Dividers Movable Partition Wall for Multi-Function HallApplications

Eco Friendly Soundproof Automatic Room Dividers Movable Partition Wall for Multi-Function Hall
Eco Friendly Soundproof Automatic Room Dividers Movable Partition Wall for Multi-Function Hall
Eco Friendly Soundproof Automatic Room Dividers Movable Partition Wall for Multi-Function Hall
Eco Friendly Soundproof Automatic Room Dividers Movable Partition Wall for Multi-Function Hall


Eco Friendly Soundproof Automatic Room Dividers Movable Partition Wall for Multi-Function Hall

The benefits of active partitions:

1. The general movable partition wall is mainly made of melamine board into a modular wall.

2. It has super operability and does not require too many complicated steps. No matter who it is, it can be used by just looking at it. It is easy to disassemble and install. In addition, the biggest advantage is that it can be freely retracted and stored, which changes the space layout. , provides a very beautiful interior decoration.

3. This kind of hotel activity partition is highly usable, and its design is the integration of parts. This is to make it easier to combine, so its combination is very strong, and it can be reused, which not only reduces the cost of customers Cost, but also play a role in environmental protection, energy saving and so on.

Fourth, the installation of our movable partition wall has a short construction period and little pollution, which means that it can quickly improve the entire project. At the same time, we will repeatedly confirm the installation plan of the hotel's movable partition with the customer before installing the movable partition wall.

5. The biggest feature of the hotel's movable partition is that it can be moved and reused many times. The characteristics of the materials it uses will not bring waste to the environment. The movable partition material is a green and environmentally friendly material, such as many company addresses. It will be relocated many times, so the enterprise needs to consider the reusability of the movable partition that needs to be installed, and the long service life is more convenient for users, so it is a relatively cheap and cost-effective decoration, which is why it is very popular.

6. The activity partitions used by the hotel can choose the color and pattern according to their own venue style, and choose a more harmonious and harmonious finish, which can make the banquet hall and other commercial spaces look brand new and enhance the visual experience.
