Model No.: MQ-PARTITION
Brand: MAGIC CUBE
Warranty Service: 5 Years
After-sales Service: Online Technical Support, Return And Replacement, Other
Engineering Solution Capability: Total Solution For Projects, Others
Application Scenario: Hotel, Hall, Home Bar, Home Office, Gym, Mall, Workshop, Office Building
Design Style: Contemporary, Scandinavian, Eclectic, Victorian, Traditional, Postmodern, Southwestern, Japanese, Modern, Mediterranean, Craftsman, Chinese, Minimalist, Coastal, Mid-Century Modern, French, Industrial, Rustic, Transitional, Midcentury, European, Tropical, Farmhouse, Asian
Place Of Origin: China
Model NO.: Movable Partitions
Type: Melamine MDF Panel, Fireproof PVC Board, Fabric
Application: Office, Hotel Banquet Hall, etc.
Thickness: 65mm, 85mm, 100mm or 125mm
Height: 3500mm~16000mm
Width: 750mm~2000mm
Sound Insulation (dB): 35-50dB
Fire Rating: 1.5 Hours
Door Panel Weight: Max 750kg/Panel
Specification: 65, 85, 100, 125
Packaging: Carton Paper Packaging, MDF Batten Cover Corners
Productivity: 5000sq/Month
Transportation: Ocean
Place of Origin: CHINA
Supply Ability: 5000sq/Month
Certificate: CE
HS Code: 76101000
Port: SHENZHEN,GUANGZHOU
Payment Type: T/T,Others
Incoterm: FOB,CIF,EXW
Soundproof Movable Walls are generally used in public workplaces such as banquet halls and exhibitions. It must be possible to create an excellent customer's activity space at the same time according to the actual situation, so that there are many business-friendly functions that can be next door.
Soundproof Movable Walls after being separated into a number of small spaces, the higher Sound Insulation coefficient will bring a lot of convenience to people. For the pursuit of private, quiet office space groups is a very good product, the price is not high, practical.
Type | 65 type, 80 type, 100 type, ultra high 100 type. |
Finish | melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel |
Density | 28~32kg/m² |
STC | 40db-50db |
Dimensions | width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg |
Structure | 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing |
Panel Suspension | Top hunge system without the need for a floor track. |
Panel Width | Each panel 600mm-1200mm. |
Track | Aluminum OR Steel Track |
Roller on panel | Single or double roller. |
Panel Frames | Heavy-duty steel-gusseted aluminum inner frames reinforced with full height. |
Top&bottm seals | Top and bottom pressure retractable seals ensure effortless moved and locked. |
Module | 700mm - 1200mm maximum. |
Panel stacking | Numerous panel stacking options for complete flexibility. |
Panel face | MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc. |
Finishes | Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard |
Ultra high 100 type
Ultra-high Movable Partition is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high partition can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.
Features
Stacking Ways
Applications
The Ultra-high Partition Wall is an existence that optimizes the space of the banquet hall. The unique charm of the partition is to make the monotonous banquet hall lobby more simple and elegant, to meet the needs of customers in multiple directions, and to design and install the plan according to the style and characteristics of the venue.
The characteristics of the hotel movable partition are as follows:
sound insulation
Our Ultra-High Partition Wall have been tested and certified by authoritative institutions, and we can design and customize them according to the requirements of different customers. Of course, it is necessary to ensure that the sound insulation of movable partitions must be maintained to a high level.
safety
Our movable partition walls are all made of aluminum alloy frames and steel parts with inner cores, which are not easy to deform. With the skilled assembly process, the stability and safety of the movable partition walls are maximized.
flexibility
With the ultra-high-strength aluminum alloy track, the partition wall door can be pushed easily and conveniently, without noise, and can be retracted and placed freely, so as to adapt to various flexible and changeable space trends. It is easy and convenient to unfold and store the movable partition wall by the strength of only one person.
Tightness:
Multiple sealing strips are installed on the Ultra-High Partition Wall, so that the partition wall can effectively increase the sealing performance of the whole wall. The nodes use memory glue to maintain this characteristic and increase the sound insulation performance.
We focus on developing a variety of partition products, and are specialized in the development, production and installation of movable partitions. We have a modern factory, a large-scale customized partition production base, with exquisite production technology and strong strength. And provide pre-sale, sale, after-sale integration of a full range of services. We have introduced foreign advanced technology and strictly abide by international standards to produce high-quality hotel activity partitions. Strict selection of production materials, mechanized cutting, rich experience in splicing production for many years, high quality and stable. The biggest advantage of our products is good quality and high stability, long life, very easy to install.
Design and customization of hotel movable partition walls
1. According to different customer needs, it is necessary to carry out one-to-one tailor-made, so as to keep improving.
2. We have a domestic professional design team, which can design and formulate a more suitable installation plan for movable partitions according to the customer's requirements and careful investigation of the customer's site.
3. With years of senior experience in the industry, our construction team conducts standardized installations to ensure that each project can be completed on time.
4. We specialize in providing high-quality and thoughtful services for foreign star-rated hotels, government and enterprise units, conference rooms and other building spaces. The market has a high praise rate and will continue to improve.
