Model No.: MQ-PARTITION
Brand: MAGIC CUBE
Main Application: Commercial Furniture
Types Of: Office Furniture
Whether To Support Mail Order Packaging (special Packaging For Cross-border E-commerce): Y
Packaging: Carton Paper Packaging, MDF Batten Cover Corners
Productivity: 5000sq/Month
Transportation: Ocean
Place of Origin: China
Supply Ability: 5000sq/Month
Certificate: CE
HS Code: 76101000
Payment Type: T/T
Incoterm: FOB,CIF,EXW
Product Description
operable wall system is a Movable Wall with general wall functions that can divide large space into small space or connect small space into large space at any time according to needs. It can play a role of multiple functions in one hall or one room. The operable wall system brings great convenience to people's work. For example, you can fold it on one side when you need it, so that the two spaces are temporarily joined to make them appear larger, which is convenient for temporary departmental meetings.
| Type | 65 type, 80 type, 100 type, ultra high 100 type. |
| Finish | melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel |
| Density | 28~32kg/m² |
| STC | 40db-50db |
| Dimensions | width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg |
| Structure | 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing |
| Panel Suspension | Top hunge system without the need for a floor track. |
| Panel Width | Each panel 600mm-1200mm. |
| Track | Aluminum OR Steel Track |
| Roller on panel | Single or double roller. |
| Panel Frames | Heavy-duty steel-gusseted aluminum inner frames reinforced with full height. |
| Top&bottm seals | Top and bottom pressure retractable seals ensure effortless moved and locked. |
| Module | 700mm - 1200mm maximum. |
| Panel stacking | Numerous panel stacking options for complete flexibility. |
| Panel face | MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc. |
| Finishes | Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard |
Ultra high 100 type
Ultra-high Sliding Movable partition is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high Sliding Movable partition can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.
Features
Stacking Ways
Applications
The hotel sliding partition panels has a variety of finish options. Because of the different needs of customers, different venue spaces and the variety of finishes, each event partition is different and very personalized. In addition to traditional materials such as plate hard packs and cloth leather soft packs, there are also new technical materials such as 3D printing and inkjet printing, so it can fully show the unique charm of your products.
When installing a hotel sliding partition panels, it is necessary to survey the surrounding environment and measure the size of the installation site to understand the overall environment and obtain the appropriate height and partition range. In order to make the partition and the scene form a strong consistency, more fashionable and good collocation, showing a strong coordinated visual effect.
The movable partition walls of the hotel banquet hall have very strict control standards in terms of materials. In order to reduce the pollution output, the movable partition walls are made of environmentally friendly and lightweight materials. Because there are no harmful substances such as formaldehyde in the panels of the movable partition, the entire installation period is very short, and the entire installation project is completed very quickly. After installation, the venue and partition can be used immediately, saving time and labor costs. For the commercial building spaces with large passenger flow such as banquet hall hotels, event partitions can meet the requirements of hotel banquet halls in all aspects such as features, functions and advantages. necessary needs.
Different hotel banquet halls will also have different functions and purposes. When setting up meeting rooms in banquet halls, a single large space cannot meet the respective needs of multiple enterprises at the same time. It is divided into corresponding small spaces with activity partitions. As long as the partition wall is set up in advance and the corresponding table and chairs are placed on the same day, it is completed.
Product Categories : Ultra-high Partition Wall
