Sound insulation partition hall

$89.99 - 129.99 /Square Meter
Sound-absorbing board varieties:
Share:
  • Product Description
Overview
Product Attributes

Model No.MQ-PARTITION

BrandMAGIC CUBE

Warranty Service5 Years

After-sales ServiceOnline Technical Support, Return And Replacement, Other

Engineering Solution CapabilityTotal Solution For Projects, Others

Application ScenarioHotel, Office Building, Mall, Hall, Gym, Home Office, Workshop

Design StyleContemporary, Postmodern, Craftsman, Traditional, Mediterranean, Mid-Century Modern, Modern, Coastal, Transitional, Minimalist, Rustic, Industrial, European, Tropical, Midcentury, Asian, Victorian, Farmhouse, Eclectic, Japanese, Scandinavian, Southwestern, Chinese, French

Place Of OriginChina

ApplicationOffice, Hotel Banquet Hall, etc.

Main MaterialAluminum Frame and Track

Soundproof MaterRock Rool , Glass Wool

Soundproof Stc40dB-50dB

DimensionsW700-1200mm, H2000-5200mm, Thickness 80-110mm

Stacking WayCentre Partiting; Side Parking

Open WaySliding Partition

Ransport PackageCarton Paper Packaging, MDF Batten Cover Corners

Model NO.Movable Partitions

TypeMelamine MDF Panel, Fireproof PVC Board, Fabric

Supply Ability & Additional Information

PackagingCarton Paper Packaging, MDF Batten Cover Corners

Productivity5000sq/Month

TransportationOcean

Place of OriginCHINA

Supply Ability5000sq/Month

CertificateCE

HS Code76101000

PortSHENZHEN,GUANGZHOU

Payment TypeT/T,Others

IncotermFOB,CIF,EXW

Packaging & Delivery
Selling Units:
Square Meter
Package Type:
Carton Paper Packaging, MDF Batten Cover Corners
Product Description


detachable partition wall are widely used for installation in various places, such as different places, different places, etc. , you need to know in detail the height and length of the customer at any location and the needs of the partition wall to design the installation plan of the partition wall size.
Because the high-quality characteristics of detachable partition wall can be used for a long time, the price of movable partition walls is much higher than that of other sound-absorbing materials, so the price of movable partition walls is very low.


Specifications

Type 65 type, 80 type, 100 type, ultra high 100 type.
Finish melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel
Density  28~32kg/m²
STC 40db-50db
Dimensions width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg
Structure 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing


Product Structure


Most Popular Customized Wood Walls Panels Partition Acoustic Wall Panels for Hotel Hall or Office
Most Popular Customized Wood Walls Panels Partition Acoustic Wall Panels for Hotel Hall or Office



Panel Suspension  Top hunge system without the need for a floor track.
Panel Width Each panel 600mm-1200mm.
Track Aluminum OR Steel Track
Roller on panel Single or double  roller.
Panel Frames  Heavy-duty steel-gusseted aluminum inner frames reinforced with  full height.
Top&bottm seals Top and bottom pressure retractable seals ensure effortless moved and locked.
Module 700mm - 1200mm maximum.
Panel stacking Numerous panel stacking options for complete flexibility.
Panel face  MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard




Most Popular Customized Wood Walls Panels Partition Acoustic Wall Panels for Hotel Hall or Office

Ultra high 100 type

    Ultra-high folding partition wall is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high folding partition wall can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.

Features

  • Load bearing of each meter is more than 2000 KGS
  • Each pulley bearing more than 1500 KGS
  • Easily moved even being pushed at waist-high
  • The panel can make a turn automatically as sliding in the straight rail


Most Popular Customized Wood Walls Panels Partition Acoustic Wall Panels for Hotel Hall or Office

Most Popular Customized Wood Walls Panels Partition Acoustic Wall Panels for Hotel Hall or Office

Stacking Ways

Most Popular Customized Wood Walls Panels Partition Acoustic Wall Panels for Hotel Hall or OfficeApplications

Most Popular Customized Wood Walls Panels Partition Acoustic Wall Panels for Hotel Hall or Office
Most Popular Customized Wood Walls Panels Partition Acoustic Wall Panels for Hotel Hall or Office
Most Popular Customized Wood Walls Panels Partition Acoustic Wall Panels for Hotel Hall or Office
Most Popular Customized Wood Walls Panels Partition Acoustic Wall Panels for Hotel Hall or Office


Most Popular Customized Wood Walls Panels Partition Acoustic Wall Panels for Hotel Hall or Office

The ultra-high movable partition is a kind of operable moveable partition, also known as the partition wall, which is a non-load-bearing component that separates the interior space of the building. When you don't need to use it, you can fold it and put it aside to make the combined space appear wider and larger. The movable partition has the characteristics of easy movement, simple operation, high Sound Insulation and fire protection, etc. It is especially suitable for hotels and Space separation in large buildings such as banquet halls. The design of this movable partition is equipped with a vertical compression fitting device to keep the partition in place very securely.

1. It supports partial disassembly and assembly, which can be reused many times. The material of the partition wall system adopts polymer technology materials, and it has the functions of fireproof, sound insulation and heat insulation. Because it is a green and environmentally friendly building material, it has a long service life. The materials for installing movable partition walls are cheaper and more durable than installing other forms of partition materials. Therefore, the activity partition is more cost-effective, and it is suitable for use in banquet halls, hotels and other places.


2. In a hotel or banquet hall, customer groups and customer needs determine the area of the separated space. In order to meet the office needs of enterprises in all walks of life at the same time, the large space with a single function is divided into multiple small spaces with different areas. Improve space utilization and flexibly change the size of the space.

3. The ultra-high movable partition wall is surrounded by a double-layer aluminum alloy frame with a thickness of about 100mm. Various methods such as oxidation and electrophoresis can be used according to customer requirements. This kind of movable partition wall adopts heavy-duty track, and the number of wheel rolling and hanging wheel sliding can reach 100,000 times. The partition wall is made of fire-proof and moisture-proof materials, which has a good sound insulation effect. In normal use, only one person can easily push the huge ultra-high operable moveable partition. Multiple small spaces used by many people can be arranged in a very short time, which is efficient and labor-saving. In today's fast-paced society, time is money. Reasonably manage time and improve work efficiency efficiently, which is why movable partition walls are so popular and accepted.


4. The strong door frame of the movable partition is equipped with a sealing strip, so that the sound insulation effect will be more significant and the sealing performance will be improved, so that the sound insulation system is complete.
