good quality decorative flexible partition wall systems
  • good quality decorative flexible partition wall systems
  • good quality decorative flexible partition wall systems
  • good quality decorative flexible partition wall systems
  • good quality decorative flexible partition wall systems
  • good quality decorative flexible partition wall systems
  • good quality decorative flexible partition wall systems

good quality decorative flexible partition wall systems

$89.99 - 129.99 /Square Meter
Sound-absorbing board varieties:
Share:
  • Product Description
< >
Overview
Product Attributes

Model No.: MQ-PARTITION

Brand: MAGIC CUBE

Warranty Service: 5 Years

After-sales Service: Online Technical Support, Return And Replacement

Engineering Solution Capability: Total Solution For Projects

Application Scenario: Hotel, Villa, Hall, Gym, Office Building, Home Office

Design Style: Contemporary, Scandinavian, Eclectic, Victorian, Traditional, Postmodern, Southwestern, Japanese, Modern, Mediterranean, Craftsman, Chinese, Minimalist, Coastal, Mid-Century Modern, French, Industrial, Rustic, Transitional, Midcentury, European, Tropical, Farmhouse, Asian

Place Of Origin: China

Model NO.: series 85 partition walls

Soundproof Material: Rock Rool , Glass Wool

Width: 600mm~1200mm

Sound Insulation (dB): 40-50dB

Fire Rating: 1.5 Hours

Door Panel Weight: Max 550kg/Panel

Specification: 8mm/10mm/12mm tempered glass

Supply Ability & Additional Information

Packaging: Carton Paper Packaging, MDF Batten Cover Corners

Productivity: 5000sq/Month

Transportation: Ocean

Place of Origin: CHINA

Supply Ability: 5000sq/Month

Certificate: CE

HS Code: 76101000

Port: SHENZHEN,GUANGZHOU

Payment Type: T/T

Incoterm: FOB,CIF,EXW

Packaging & Delivery
Selling Units:
Square Meter
Package Type:
Carton Paper Packaging, MDF Batten Cover Corners
Product Description

Nowadays, many hotels want to change the planning and personality, often need to change the space personality, the partition wall to meet the needs of the hotel. More advanced banquet halls and other places will seek to have private space, and the operable moveable partition has such advantages while the Sound Insulation coefficient is also very high. After being separated into a number of small spaces, the higher sound insulation coefficient will bring a lot of convenience to people. For the pursuit of private, install quiet operable moveable partition make office space groups is a very good product, the price is not high, practical.

Specifications

Type 65 type, 80 type, 100 type, ultra high 100 type.
Finish melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel
Density  28~32kg/m²
STC 40db-50db
Dimensions width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg
Structure 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing



Product Structure


High Sound Insulation Acoustic Sliding Dividers Sliding Soundproof Partition for Hall or Office
High Sound Insulation Acoustic Sliding Dividers Sliding Soundproof Partition for Hall or Office



Panel Suspension  Top hunge system without the need for a floor track.
Panel Width Each panel 600mm-1200mm.
Track Aluminum OR Steel Track
Roller on panel Single or double  roller.
Panel Frames  Heavy-duty steel-gusseted aluminum inner frames reinforced with  full height.
Top&bottm seals Top and bottom pressure retractable seals ensure effortless moved and locked.
Module 700mm - 1200mm maximum.
Panel stacking Numerous panel stacking options for complete flexibility.
Panel face  MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard




High Sound Insulation Acoustic Sliding Dividers Sliding Soundproof Partition for Hall or Office

Ultra high 100 type

    folding partition wall is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high folding partition wall can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.

Features

  • Load bearing of each meter is more than 2000 KGS
  • Each pulley bearing more than 1500 KGS
  • Easily moved even being pushed at waist-high
  • The panel can make a turn automatically as sliding in the straight rail


High Sound Insulation Acoustic Sliding Dividers Sliding Soundproof Partition for Hall or Office

High Sound Insulation Acoustic Sliding Dividers Sliding Soundproof Partition for Hall or Office

Stacking Ways

High Sound Insulation Acoustic Sliding Dividers Sliding Soundproof Partition for Hall or OfficeApplications

High Sound Insulation Acoustic Sliding Dividers Sliding Soundproof Partition for Hall or Office
High Sound Insulation Acoustic Sliding Dividers Sliding Soundproof Partition for Hall or Office
High Sound Insulation Acoustic Sliding Dividers Sliding Soundproof Partition for Hall or Office
High Sound Insulation Acoustic Sliding Dividers Sliding Soundproof Partition for Hall or Office


High Sound Insulation Acoustic Sliding Dividers Sliding Soundproof Partition for Hall or Office

As the name suggests, the detachable partition wall is used in general large banquet halls or conference centers. The height of the ceiling is relatively high, usually as high as 8 meters or even 12 meters, and it will reach a height of 15 meters. This ultra-high type detachable partition wall is selected for the use of the so-called multi-functional hall.

In such a high place, the door panel will be much heavier than the door panel of the general movable partition, which means that the partition used is completely hung on the steel structure, and the structure of the ceiling needs to bear the weight of tons or even more than ten tons. The material selection and installation requirements for the steel frame are very high.

Generally, the structure of the house is more complex, the conventional concrete steel structure, tennis steel structure or simple structure, etc., for different

For the housing structure, professional designers need to investigate the site and then make a professional steel frame installation plan. With our many years of experience, we will definitely work out the most suitable installation solution for you.

In order to avoid the result of failure after installing the steel frame, it is necessary to focus on the span of the steel frame when formulating the plan, and the specification of the steel to measure the load-bearing value. These factors are indispensable, otherwise, the installation of the steel frame will fail.

Our active partition is a partition wall that can be easily installed, so that you can reasonably use the limited space, no longer because the space is too small to bring problems and troubles.
