Model No.: MA-PARTITION
Brand: MAGIC CUBE
Warranty Service: 5 Years
After-sales Service: Online Technical Support, Return And Replacement, Other
Engineering Solution Capability: Total Solution For Projects, Others
Application Scenario: Hotel, Home Office, Hall, Gym, Workshop, Office Building
Design Style: Contemporary, Scandinavian, Eclectic, Victorian, Traditional, Postmodern, Southwestern, Japanese, Modern, Mediterranean, Craftsman, Chinese, Minimalist, Coastal, Mid-Century Modern, French, Industrial, Rustic, Transitional, Midcentury, European, Tropical, Farmhouse, Asian
Place Of Origin: China
Type: Melamine MDF Panel, Fireproof PVC Board, Fabric
Application: Office, Hotel Banquet Hall, etc.
Main Material: Rock Rool , Glass Wool
Soundproof Mater: Rock Rool , Glass Wool
Soundproof Stc: 40dB-50dB
Stacking Way: Centre Partiting; Side Parking
Dimensions: W700-1200mm, H2000-5200mm, Thickness 80-110mm
Ransport Package: Carton Paper Packaging, MDF Batten Cover Corners
Model NO.: Movable Partitions
Packaging: Carton Paper Packaging, MDF Batten Cover Corners
Productivity: CHINA
Transportation: Ocean
Place of Origin: CHINA
Supply Ability: 10-15
Certificate: CE
HS Code: 76101000
Port: SHENZHEN,GUANGZHOU
Payment Type: T/T
Incoterm: FOB,CIF,EXW
Product Description
The ultra-high Movable Partition Wall can be up to 16 meters, and the ultra-high movable partition wall brings a lot of convenience to people's work. The raw material of the wood board can choose MDF, melamine board and flame retardant plywood as the board.
It must be possible to create an excellent customer's activity space at the same time according to the actual situation, so that there are many business-friendly functions that can be next door. In order to avoid the intermittent waiting of scratches or back shadows during transportation, After the Movable Partition Wall is sent to the installation site, finishing processing will be carried out.
Specifications
| Type | 65 type, 80 type, 100 type, ultra high 100 type. |
| Finish | melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel |
| Density | 28~32kg/m² |
| STC | 40db-50db |
| Dimensions | width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg |
| Structure | 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing |
| Panel Suspension | Top hunge system without the need for a floor track. |
| Panel Width | Each panel 600mm-1200mm. |
| Track | Aluminum OR Steel Track |
| Roller on panel | Single or double roller. |
| Panel Frames | Heavy-duty steel-gusseted aluminum inner frames reinforced with full height. |
| Top&bottm seals | Top and bottom pressure retractable seals ensure effortless moved and locked. |
| Module | 700mm - 1200mm maximum. |
| Panel stacking | Numerous panel stacking options for complete flexibility. |
| Panel face | MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc. |
| Finishes | Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard |
Ultra high 100 type
Ultra-high Moveable Wall is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type Moveable Wall is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high partition can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.
Features
Stacking Ways
Applications
How to Install Mobile Partitions
1. The size of the upper track box of the Moveable Partition Wall should be guaranteed to be 12cm high and 9cm wide. Install the track in the track box to hang the mobile partition on the track.
What are the characteristics of the movable partition, how to install the Moveable Partition Wall ？
2. Under normal circumstances, it is more suitable for the partition fan of the mobile partition to be about 80 cm by 200 cm. The door of this structure is relatively stable, and the appearance will be more beautiful, so the width and height of the mobile partition must maintain the golden size.
3. When installing mobile partitions, it is best not to use mobile partitions that fall to the top, because the swing range is too large when pushing and pulling, and the use of a long time will cause the mobile partitions to be easily deformed, making it impossible to open the partition door panel. This affects the use of partitions.
4. When installing the mobile partition track, the upper track should be fixed, and then the upper track should be installed with the gravity cone and the two ends and midpoints of the upper track. Be sure to pay attention to placing vertical lines at both ends of the track, and fix the lower track with three points to ensure that the upper and lower tracks are completely parallel, so that the partition can be in the best state.
The above content is a general introduction to the characteristics of movable partitions and how to install them. Finally, remind everyone that the choice of mobile partition must use formal materials to ensure safety and quality.
Product Categories : Hall Sliding Partition
