Model No.: MQ-PZRTITION
Brand: MAGIC CUBE
Warranty Service: 5 Years
After-sales Service: Online Technical Support, Return And Replacement, Other
Engineering Solution Capability: Total Solution For Projects, Others
Application Scenario: Hotel, Hall, Gym, Mall, Workshop, Office Building, Home Office
Design Style: Contemporary, Scandinavian, Eclectic, Victorian, Traditional, Postmodern, Southwestern, Japanese, Modern, Mediterranean, Craftsman, Chinese, Minimalist, Coastal, Mid-Century Modern, French, Industrial, Rustic, Transitional, Midcentury, European, Tropical, Farmhouse, Asian
Place Of Origin: China
Model NO.: Movable Partitions
Type: Melamine MDF Panel, Fireproof PVC Board, Fabric
Application: Office, Hotel Banquet Hall, etc.
Main Material: Aluminum Frame and Track
Soundproof Mater: Rock Rool , Glass Wool
Soundproof Stc: 40dB-50dB
Dimensions: W700-1200mm, H2000-5200mm, Thickness 80-110mm
Stacking Way: Centre Partiting; Side Parking
Open Way: Sliding Partition
Ransport Package: Carton Paper Packaging, MDF Batten Cover Corners
Packaging: Carton Paper Packaging, MDF Batten Cover Corners
Productivity: 5000sq/Month
Transportation: Ocean
Place of Origin: CHINA
Supply Ability: 5000sq/Month
Certificate: CE
HS Code: 76101000
Port: SHENZHEN,GUANGZHOU
Payment Type: T/T,Others
Incoterm: FOB,CIF,EXW
In the lobby of a large hotel, a large and spacious space cannot be used effectively except for large-scale events. Therefore, if it needs to be effectively used, a Movable Partition Wall must be used, because the Movable Partition Wall is practical and beautiful. For hotels that need to contact customers The place, the elegant and atmospheric movable partition wall is bright and pleasing to the eyes. The floor height of any size of space has a corresponding type of movable partition wall, which supports personal customization and can also set the style of the partition wall by itself.
| Type | 65 type, 80 type, 100 type, ultra high 100 type. |
| Finish | melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel |
| Density | 28~32kg/m² |
| STC | 40db-50db |
| Dimensions | width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg |
| Structure | 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing |
| Panel Suspension | Top hunge system without the need for a floor track. |
| Panel Width | Each panel 600mm-1200mm. |
| Track | Aluminum OR Steel Track |
| Roller on panel | Single or double roller. |
| Panel Frames | Heavy-duty steel-gusseted aluminum inner frames reinforced with full height. |
| Top&bottm seals | Top and bottom pressure retractable seals ensure effortless moved and locked. |
| Module | 700mm - 1200mm maximum. |
| Panel stacking | Numerous panel stacking options for complete flexibility. |
| Panel face | MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc. |
| Finishes | Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard |
Ultra high 100 type
Ultra-high Moveable Wall is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high Moveable Wall can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.
Features
Stacking Ways
Applications
As the name suggests, the ultra-high-type event partition is used in general large banquet halls or conference centers. The height of the ceiling is relatively high, usually as high as 8 meters or even 12 meters, and it will reach a height of 15 meters. This ultra-high type movable partition wall is selected for the use of the so-called multi-functional hall.
In such a high place, the door panel will be much heavier than the door panel of the general movable partition, which means that the partition used is completely hung on the steel structure, and the structure of the ceiling needs to bear the weight of tons or even more than ten tons. The material selection and installation requirements for the steel frame are very high.
Generally, the structure of the house is more complex, the conventional concrete steel structure, tennis steel structure or simple structure, etc., for different
For the housing structure, professional designers need to investigate the site and then make a professional steel frame installation plan. With our many years of experience, we will definitely work out the most suitable installation solution for you.
In order to avoid the result of failure after installing the steel frame, it is necessary to focus on the span of the steel frame when formulating the plan, and the specification of the steel to measure the load-bearing value. These factors are indispensable, otherwise, the installation of the steel frame will fail.
In order to avoid the result of failure after installing the steel frame, it is necessary to focus on the span of the steel frame when formulating the plan, and the specification of the steel to measure the load-bearing value. These factors are indispensable, otherwise, the installation of the steel frame will fail.
Product features of ultra-high Movable Partition Wall:
1. There is no need to install rails on the ground. The Movable Partition Wall panels are connected to the hanging installation rails on the ceiling. The door panels rely on the ceiling rails to push and use without noise. When you need to use it, press down the bead, and the movable partition wall can be installed soon.
2. The door panel is equipped with a retractable structure up and down.
3. After the large space is divided into small spaces, the thermal insulation performance and Sound Insulation effect will be more significant.
4. They are all made of high-efficiency flame-retardant fire-resistant materials, which have good fire-proof performance and can immediately block the re-burning of the fire source. The safety factor is high, the product data meets the national standards, and the materials are environmentally friendly, energy-saving and renewable.
5. The exterior of the partition door panel can be arbitrarily designed with decorative surfaces according to the needs of customers and the style of the venue.
Product Categories : Hall Sliding Partition
