Soundproofing Sliding Aluminium sliding door partition wall

$89.99 - 129.99 /Square Meter
Sound-absorbing board varieties:
Share:
  • Product Description
Overview
Product Attributes

Model No.MQ-PARTITION

BrandMAGIC CUBE

Warranty Service5 Years

After-sales ServiceOnline Technical Support, Return And Replacement, Other

Engineering Solution CapabilityTotal Solution For Projects, Others

Application ScenarioHotel, Mall, Hall, Gym, Home Bar, Home Office, Office Building, Workshop

Design StyleContemporary, Scandinavian, Eclectic, Victorian, Traditional, Postmodern, Southwestern, Japanese, Modern, Mediterranean, Craftsman, Chinese, Minimalist, Coastal, Mid-Century Modern, French, Industrial, Rustic, Transitional, Midcentury, European, Tropical, Farmhouse, Asian

Place Of OriginChina

Model NO.Movable Partitions

TypeMelamine MDF Panel, Fireproof PVC Board, Fabric

ApplicationOffice, Hotel Banquet Hall, etc.

Main MaterialAluminum Frame and Track

Soundproof MaterRock Rool , Glass Wool

Soundproof Stc40dB-50dB

DimensionsW700-1200mm, H2000-5200mm, Thickness 80-110mm

Stacking WayCentre Partiting; Side Parking

Open WaySliding Partition

Ransport PackageCarton Paper Packaging, MDF Batten Cover Corners

Supply Ability & Additional Information

PackagingCarton Paper Packaging, MDF Batten Cover Corners

Productivity5000sq/Month

TransportationOcean

Place of OriginCHINA

Supply Ability5000sq/Month

CertificateCE

HS Code76101000

PortSHENZHEN,GUANGZHOU

Payment TypeT/T,Others

IncotermFOB,CIF,EXW

Packaging & Delivery
Selling Units:
Square Meter
Package Type:
Carton Paper Packaging, MDF Batten Cover Corners

Product Description


A good hotel will also have a good detachable partition wall, the partition is very important, and the partition installation system next door is required for partition installation, which is convenient and accurate.

Due to the large volume of the ultra-high movable partition wall, in order to avoid the damage of the detachable partition wall door panel during transportation, it is generally difficult to install the ultra-high movable partition wall by splicing it on site.



Specifications

Type 65 type, 80 type, 100 type, ultra high 100 type.
Finish melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel
Density  28~32kg/m²
STC 40db-50db
Dimensions width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg
Structure 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing


Product Structure


Eco Friendly Acoustic Wall Interior Decoration Acoustical Wall Foldable Acoustic Partition Wall for Hall or Hotel
Eco Friendly Acoustic Wall Interior Decoration Acoustical Wall Foldable Acoustic Partition Wall for Hall or Hotel



Panel Suspension  Top hunge system without the need for a floor track.
Panel Width Each panel 600mm-1200mm.
Track Aluminum OR Steel Track
Roller on panel Single or double  roller.
Panel Frames  Heavy-duty steel-gusseted aluminum inner frames reinforced with  full height.
Top&bottm seals Top and bottom pressure retractable seals ensure effortless moved and locked.
Module 700mm - 1200mm maximum.
Panel stacking Numerous panel stacking options for complete flexibility.
Panel face  MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard




Eco Friendly Acoustic Wall Interior Decoration Acoustical Wall Foldable Acoustic Partition Wall for Hall or Hotel

Ultra high 100 type

    Ultra-high folding partition wall is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high folding partition wall can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.

Features

  • Load bearing of each meter is more than 2000 KGS
  • Each pulley bearing more than 1500 KGS
  • Easily moved even being pushed at waist-high
  • The panel can make a turn automatically as sliding in the straight rail


Eco Friendly Acoustic Wall Interior Decoration Acoustical Wall Foldable Acoustic Partition Wall for Hall or Hotel

Eco Friendly Acoustic Wall Interior Decoration Acoustical Wall Foldable Acoustic Partition Wall for Hall or Hotel

Stacking Ways

Eco Friendly Acoustic Wall Interior Decoration Acoustical Wall Foldable Acoustic Partition Wall for Hall or HotelApplications

Eco Friendly Acoustic Wall Interior Decoration Acoustical Wall Foldable Acoustic Partition Wall for Hall or Hotel
Eco Friendly Acoustic Wall Interior Decoration Acoustical Wall Foldable Acoustic Partition Wall for Hall or Hotel
Eco Friendly Acoustic Wall Interior Decoration Acoustical Wall Foldable Acoustic Partition Wall for Hall or Hotel
Eco Friendly Acoustic Wall Interior Decoration Acoustical Wall Foldable Acoustic Partition Wall for Hall or Hotel


Eco Friendly Acoustic Wall Interior Decoration Acoustical Wall Foldable Acoustic Partition Wall for Hall or Hotel

The track of the operable moveable partition is installed on the ceiling, there is no track on the ground, no ground track is suspended, but it is more stable and reliable. The movable partition wall is generally made of PAR sound-absorbing glass fiber Sound Insulation cotton, and the partition wall door panel is surrounded by an all-inclusive aluminum frame, the board is made of melamine board, and the board is sandwiched with sound insulation cotton. Melamine board has relatively good fire performance, and this board is available in a variety of colors and styles. Through proper craftsmanship, the entire wall can be flexibly and conveniently retracted through the track. Check. When accepting movable partitions, first check whether the rails of the operable moveable partition are firmly connected and whether the positions are closely overlapped; whether they can feel safe, stable, and sensitive when pushing and pulling, and push and pull several times, as long as any inappropriate jam occurs. It should be pointed out to communicate effectively with the installer to solve the problem, observe whether the wall is smooth and smooth, and use the touched wall to experience the hand feel. If there is a sticky or uneven place, manual grinding and optimization should be required; and the last point is to ensure the activity The partition wall remains noise-free when pushed and pulled.

The use of ultra-high movable partition walls is to effectively separate the effective space and achieve a good decorative effect. What kind of material to choose for the partition wall is mainly to consider whether the material is moisture-proof, fire-proof and its toughness and other factors. There is also the use of movable partitions in hotels, which cannot be ignored is whether the board has moth-eaten problems. Some inferior boards may be worn after a long time of use, which may cause moth-eaten phenomenon, but high-quality movable partition walls will not appear. such a problem. Our ultra-high-profile partition walls are meticulously processed and attention to detail, and every aspect of production is strictly controlled.
