Interior decoration soundproof movable wall

$89.99 - 129.99 /Square Meter
Sound-absorbing board varieties:
Share:
  • Product Description
Overview
Product Attributes

Model No.MQ-PZRTITION

BrandMAGIC CUBE

Warranty Service5 Years

After-sales ServiceOnline Technical Support, Return And Replacement, Other

Engineering Solution CapabilityTotal Solution For Projects, Others

Application ScenarioHotel, Hall, Home Bar, Home Office, Office Building, Workshop, Gym

Design StyleContemporary, Scandinavian, Eclectic, Victorian, Traditional, Postmodern, Southwestern, Japanese, Modern, Mediterranean, Craftsman, Chinese, Minimalist, Coastal, Mid-Century Modern, French, Industrial, Rustic, Transitional, Midcentury, European, Tropical, Farmhouse, Asian

Place Of OriginChina

Model NO.Movable Partitions

TypeMelamine MDF Panel, Fireproof PVC Board, Fabric

Thickness65mm, 85mm, 100mm or 125mm

Height3500mm~16000mm

Width750mm~2000mm

Sound Insulation (dB)35-50dB

Fire Rating1.5 Hours

Door Panel WeightMax 750kg/Panel

Motor PowerAC150V~250V

Retractable Range Of Top/Bottom Seals25mm

Supply Ability & Additional Information

PackagingCarton Paper Packaging, MDF Batten Cover Corners

Productivity5000sq/Month

TransportationOcean

Place of OriginCHINA

Supply Ability5000sq/Month

CertificateCE

HS Code76101000

PortSHENZHEN,GUANGZHOU

Payment TypeT/T,Others

IncotermFOB,CIF,EXW

Packaging & Delivery
Selling Units:
Square Meter
Package Type:
Carton Paper Packaging, MDF Batten Cover Corners
Product Description

folding partition wall manufacturers generally use an event and staged event to hold events and hold events. , the activities of the show to cover the activities of the seal, so folding partition wallwill not stay on the ground and worry that it will affect the physical and mental health of others when it is not in use.




Specifications

Type 65 type, 80 type, 100 type, ultra high 100 type.
Finish melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel
Density  28~32kg/m²
STC 40db-50db
Dimensions width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg
Structure 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing


Product Structure


Electrically Operated Semi-Automatic Operable Partition for Office Meeting Room, Conference Room
Electrically Operated Semi-Automatic Operable Partition for Office Meeting Room, Conference Room



Panel Suspension  Top hunge system without the need for a floor track.
Panel Width Each panel 600mm-1200mm.
Track Aluminum OR Steel Track
Roller on panel Single or double  roller.
Panel Frames  Heavy-duty steel-gusseted aluminum inner frames reinforced with  full height.
Top&bottm seals Top and bottom pressure retractable seals ensure effortless moved and locked.
Module 700mm - 1200mm maximum.
Panel stacking Numerous panel stacking options for complete flexibility.
Panel face  MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard




Electrically Operated Semi-Automatic Operable Partition for Office Meeting Room, Conference Room

Ultra high 100 type

    Ultra-high operable moveable partition is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type operable moveable partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high partition can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.

Features

  • Load bearing of each meter is more than 2000 KGS
  • Each pulley bearing more than 1500 KGS
  • Easily moved even being pushed at waist-high
  • The panel can make a turn automatically as sliding in the straight rail


Electrically Operated Semi-Automatic Operable Partition for Office Meeting Room, Conference Room

Electrically Operated Semi-Automatic Operable Partition for Office Meeting Room, Conference Room

Stacking Ways

Electrically Operated Semi-Automatic Operable Partition for Office Meeting Room, Conference RoomApplications

Electrically Operated Semi-Automatic Operable Partition for Office Meeting Room, Conference Room
Electrically Operated Semi-Automatic Operable Partition for Office Meeting Room, Conference Room
Electrically Operated Semi-Automatic Operable Partition for Office Meeting Room, Conference Room
Electrically Operated Semi-Automatic Operable Partition for Office Meeting Room, Conference Room


Electrically Operated Semi-Automatic Operable Partition for Office Meeting Room, Conference Room

The commonly used hotel movable partitions have a high enough Sound Insulation coefficient, but in order to meet customers with stronger sound insulation effects, we need to strengthen the sound insulation materials when making partitions.

Ways to improve sound insulation

If a partition product wants to obtain high-quality sound insulation, it cannot just focus on the improvement of thickness. Because it also needs to combine the density of the material, the sound absorption energy, the method of sound insulation treatment and the degree of fit. Mainly a few more points:

1. The material of the movable partition sound insulation cotton used in the hotel banquet hall needs to have strong sound absorption performance, moderate density, and absorb audio at the reflection angle to reduce the decibel effect;

2. The partition profiles must be precise in technology, horizontal and vertical, without special protrusions and asymmetry, to ensure that the detachable partition wall can ensure the airtightness when combining partition walls, so as to achieve better noise reduction effect.

3. The material inside the movable clapboard is made of double-layer sound insulation cotton, which is a better sound insulation material, which can effectively isolate noises such as normal speech and humming.

4. The internal materials should be precisely matched, and the sound insulation material should preferably be taken from pure natural materials. Because it is a sealed space, more attention should be paid to the internal materials.

5. For those who need to pursue higher air tightness, in addition to the movable partition, it is necessary to set up soundproof curtains or other soundproof furniture;

6. The movable partition is not made of ordinary medium-density board, and needs to use sound-absorbing board or special flame-retardant cloth.

The reason for the aging of the partition

The specific details of ultra-high movable partition products

Ultra-high screen is a kind of detachable partition wall, which can also be called the maximum heavy-duty ultra-high temperature screen of 16 meters. It is also very easy to push and pull the ultra-high type movable partition. Used in large-scale banquet events, the banquet hall often becomes a veritable "wall" in the conference hall. The partitions of this series of activities are intermittent, used in restaurants, training rooms and small conference rooms in modern hotels. It can also be used as a frequently used board for stickers or Hanging paintings can also be used as ordinary paintings or hanging paintings. Various open doors can also promote various mobile office exhibitions, which play a role in preventing theft.
