Acoustic Wooden soundproof movable partition wall

operable moveable partition are often used in hotels because the hotel banquet halls, hotel conference rooms and restaurants in the hotel lobby are flexible and easy to operate in order to create multiple independent small spaces. favorite. Take the hotel conference room as an example. The hotel conference room needs to meet the needs of enterprises from all walks of life. The number of people in the conference room is as small as 20 or 30, and the maximum number is hundreds. The number of people is very different, and it is difficult to carry out work smoothly. The emergence of ultra-high operable moveable partition solves this problem, so that we can use the space of the conference room more efficiently.

The reason why the hotel conference room can create the space required by various groups of people, the movable partition wall has the outstanding characteristics compared with other partition walls:

Construction process:

1) Install the track

There are two kinds of track options for movable partition walls, one is a suspended track, and the other is a supporting track. The guide block used in the suspended track is called the suspension guide, and its fixing method is to install the pulley on the top surface of the partition fan, which is connected with the suspended track above. The size of the track and pulley must be selected according to the weight that can be carried. Light movable partition wall, the track is fixed on the wooden frame or steel frame along the top with wood screws or counterscrew. For heavy-duty movable partition walls, the track must be screwed or welded directly to the steel frame. The support guide of the support track is installed at the lower part of the partition, and forms the lower support point with the ground track. The track is fixed with expansion bolts and track embedded parts, and guide rails are also installed on the wooden frame along the top. The interaction force of the upper part and the lower part balances the load pressure brought by the movable partition wall to the ground and ceiling steel frame, so that the movable partition wall can enhance the durability.

Matters needing attention when installing the track: First, according to the specific conditions of the track, install the pulley or track in advance, and reserve the opening (usually 1/2 of the partition against the wall).

2) Install the movable panel

According to the installation method, accurately draw the pulley line on each door panel, and then fix the pulley's fixing frame to the upper or lower tower of the partition with screws; install the door panels into the track one by one in order, and adjust each door panel. , make sure they are all perpendicular to the ground. And all of them can be pushed, pulled and rotated flexibly, and finally each door panel is connected and fixed. Under normal circumstances, the adjacent door panels are connected by hinges.

3) Finishes

The decoration of the veneer should be carried out according to the requirements of the hotel interior design. Generally, soft bags, cold-installed solid wood boards, veneer panels, glass inlays, etc. will be used. The decoration and construction of the veneer shall be carried out according to the corresponding requirements of the second standard. After the veneer is finished, the painting or finishing can be carried out.

4) Debugging:

After the door panel of the movable partition wall is installed, the details of the door panel should be debugged, such as the height of the door panel and the tightness of the door panel.

Wait, after debugging, clean up the site and complete all the installation work.
