Model No.: MQ-PARTITION
Brand: MAGIC CUBE
Warranty Service: 5 Years
After-sales Service: Online Technical Support, Return And Replacement, Other
Engineering Solution Capability: Total Solution For Projects, Others
Application Scenario: Hotel, Office Building, Home Office, Workshop, Hall, Gym, Mall
Place Of Origin: China
Model NO.: Movable Partitions
Type: Melamine MDF Panel, Fireproof PVC Board, Fabric
Application: Office, Hotel Banquet Hall, etc.
Main Material: Aluminum Frame and Track
Soundproof Mater: Rock Rool , Glass Wool
Soundproof Stc: 40dB-50dB
Dimensions: W700-1200mm, H2000-5200mm, Thickness 80-110mm
Stacking Way: Centre Partiting; Side Parking
Open Way: Sliding Partition
Ransport Package: Carton Paper Packaging, MDF Batten Cover Corners
Packaging: Carton Paper Packaging, MDF Batten Cover Corners
Productivity: 5000sq/Month
Transportation: Ocean
Place of Origin: CHINA
Supply Ability: 5000sq/Month
Certificate: CE
HS Code: 76101000
Port: SHENSZHEN,GUANGZHOU
Payment Type: T/T,Others
Incoterm: FOB,CIF,EXW
In the lobby of a large hotel, a large and spacious space cannot be used effectively except for large-scale events. Therefore, if it needs to be effectively used, a movable partition wall must be used, because the Movable Partition Wall is practical and beautiful. For hotels that need to contact customers The place, the elegant and atmospheric movable partition wall is bright and pleasing to the eyes. The floor height of any size of space has a corresponding type of movable partition wall, which supports personal customization and can also set the style of the Movable Partition Wall by itself.
Specifications
Type | 65 type, 80 type, 100 type, ultra high 100 type. |
Finish | melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel |
Density | 28~32kg/m² |
STC | 40db-50db |
Dimensions | width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg |
Structure | 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing |
Panel Suspension | Top hunge system without the need for a floor track. |
Panel Width | Each panel 600mm-1200mm. |
Track | Aluminum OR Steel Track |
Roller on panel | Single or double roller. |
Panel Frames | Heavy-duty steel-gusseted aluminum inner frames reinforced with full height. |
Top&bottm seals | Top and bottom pressure retractable seals ensure effortless moved and locked. |
Module | 700mm - 1200mm maximum. |
Panel stacking | Numerous panel stacking options for complete flexibility. |
Panel face | MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc. |
Finishes | Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard |
Ultra high 100 type
Ultra-high Moveable Partition Wall is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high Moveable Partition Wall can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.
Features
Stacking Ways
Applications
The specific details of ultra-high Movable Wall ,Moveable Wall products
Ultra-high screen is a kind of movable screen, which can also be called the maximum heavy-duty ultra-high temperature screen of 16 meters. It is also very easy to push and pull the ultra-high type movable partition. Used in large-scale banquet events, the banquet hall often becomes a veritable "wall" in the conference hall. The partitions of this series of activities are intermittent, used in restaurants, training rooms and small conference rooms in modern hotels. It can also be used as a frequently used board for stickers or Hanging paintings can also be used as ordinary paintings or hanging paintings. Various open doors can also promote various mobile office exhibitions, which play a role in preventing theft.
The applicable height of space separation is 7 meters to 16 meters, and the Sound Insulation effect of high compartments is as high as 53 decibels. It can be used in large multi-purpose halls, hotel banquet halls, conference and exhibition centers, gymnasiums and auditoriums and other tall places.
The ultra-high movable partition walls are all surrounded by double-layer aluminum alloy frames. It is necessary to adopt various methods such as oxidation and electrophoresis according to customer requirements.
The heavy-duty follow-rail used for ultra-high movable partitions, the number of times the rolling suspension wheel of the model can slide up to 100,000 times, has good technology in the partition industry. The applicable height is 8m-17m. The maximum load-bearing of the rail is 1250kg/m, and the maximum sound insulation coefficient of the Movable Wall ,Moveable Wall is 60dB. Generally, it can be widely used in airports, large exhibition halls and other large places.
There are also similarities between movable partition walls and traditional fixed screen partitions, that is, the functional characteristics of blocking sight lines and separating space, but the effect of dividing space by movable partition walls is more significant than that of traditional ones, which can be used anytime, anywhere. According to different actual needs, a number of different areas are divided to use the space. Indoor places, such as temporary reception rooms or conference rooms, can be enclosed by movable partition walls, and it does not affect the normal work around, which is convenient and fast, making the indoor space more comfortable. Rich and diverse. When it is not needed, it can be stored and moved to the storage room, so as not to affect the viewing and functionality of the overall environment.
