Office partitions boards Mobile partitions

$89.99 - 129.99 /Square Meter
Sound-absorbing board varieties:
Share:
  • Product Description
Overview
Product Attributes

Model No.MQ-PARTITION

BrandMAGIC CUBE

Warranty Service5 Years

After-sales ServiceOnline Technical Support, Return And Replacement, Other

Engineering Solution CapabilityTotal Solution For Projects, Others

Application ScenarioHotel, Office Building, Mall, Hall, Gym, Home Office, Workshop

Design StyleContemporary, Postmodern, Craftsman, Traditional, Mediterranean, Mid-Century Modern, Coastal, Transitional, Modern, Minimalist, Rustic, Tropical, Industrial, European, Victorian, Midcentury, Asian, Eclectic, Japanese, Farmhouse, Chinese, Southwestern, Scandinavian, French

Place Of OriginChina

Model NO.Movable Partitions

TypeMelamine MDF Panel, Fireproof PVC Board, Fabric

ApplicationOffice, Hotel Banquet Hall, etc.

Main MaterialAluminum Frame and Track

Soundproof MaterRock Rool , Glass Wool

Soundproof Stc40dB-50dB

DimensionsW700-1200mm, H2000-5200mm, Thickness 80-110mm

Stacking WayCentre Partiting; Side Parking

Open WaySliding Partition

Ransport PackageCarton Paper Packaging, MDF Batten Cover Corners

Supply Ability & Additional Information

PackagingCarton Paper Packaging, MDF Batten Cover Corners

Productivity5000sq/Month

TransportationOcean

Place of OriginCHINA

Supply Ability5000sq/Month

CertificateCE

HS Code76101000

PortSHENZHEN,GUANGZHOU

Payment TypeT/T,Others

IncotermFOB,CIF,EXW

Packaging & Delivery
Selling Units:
Square Meter
Package Type:
Carton Paper Packaging, MDF Batten Cover Corners
Product Description


In addition to the use of mobile professional space, the movable partition of the hotel is a practical appearance change. Because its partition is flexible and free to move, its traditional movable partition partition space, the space is divided in this way, its installation cycle is very short, and the installation of large format partition boards can be completed, because the installation of movable partition also Has a complete preset function. Set rules and simple system assembly method, no gas and polluting waste will be released after construction.



Specifications


Type 65 type, 80 type, 100 type, ultra high 100 type.
Finish melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel
Density  28~32kg/m²
STC 40db-50db
Dimensions width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg
Structure 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing


Product Structure


Fireproof Material Operable Acoustic Partition Walls Movable Room Partition Walls for Office or Studio
Fireproof Material Operable Acoustic Partition Walls Movable Room Partition Walls for Office or Studio



Panel Suspension  Top hunge system without the need for a floor track.
Panel Width Each panel 600mm-1200mm.
Track Aluminum OR Steel Track
Roller on panel Single or double  roller.
Panel Frames  Heavy-duty steel-gusseted aluminum inner frames reinforced with  full height.
Top&bottm seals Top and bottom pressure retractable seals ensure effortless moved and locked.
Module 700mm - 1200mm maximum.
Panel stacking Numerous panel stacking options for complete flexibility.
Panel face  MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard




Fireproof Material Operable Acoustic Partition Walls Movable Room Partition Walls for Office or Studio

Ultra high 100 type

    Ultra-high soundproof movable partition is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high soundproof movable partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high partition can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.

Features

  • Load bearing of each meter is more than 2000 KGS
  • Each pulley bearing more than 1500 KGS
  • Easily moved even being pushed at waist-high
  • The panel can make a turn automatically as sliding in the straight rail


Fireproof Material Operable Acoustic Partition Walls Movable Room Partition Walls for Office or Studio

Fireproof Material Operable Acoustic Partition Walls Movable Room Partition Walls for Office or Studio

Stacking Ways

Fireproof Material Operable Acoustic Partition Walls Movable Room Partition Walls for Office or StudioApplications

Fireproof Material Operable Acoustic Partition Walls Movable Room Partition Walls for Office or Studio
Fireproof Material Operable Acoustic Partition Walls Movable Room Partition Walls for Office or Studio
Fireproof Material Operable Acoustic Partition Walls Movable Room Partition Walls for Office or Studio
Fireproof Material Operable Acoustic Partition Walls Movable Room Partition Walls for Office or Studio


Fireproof Material Operable Acoustic Partition Walls Movable Room Partition Walls for Office or Studio

The hotel event partition is an existence that optimizes the space of the banquet hall. The unique charm of the partition is to make the monotonous banquet hall lobby more simple and elegant, to meet the needs of customers in multiple directions, and to design and install the plan according to the style and characteristics of the venue.



The characteristics of the hotel movable partition are as follows:

Sound Insulation

Our movable acoustic partition have been tested and certified by authoritative institutions, and we can design and customize them according to the requirements of different customers. Of course, it is necessary to ensure that the sound insulation of movable partitions must be maintained to a high level.

safety

Our movable acoustic partition  are all made of aluminum alloy frames and steel parts with inner cores, which are not easy to deform. With the skilled assembly process, the stability and safety of the movable partition walls are maximized.

flexibility

With the ultra-high-strength aluminum alloy track, the partition wall door can be pushed easily and conveniently, without noise, and can be retracted and placed freely, so as to adapt to various flexible and changeable space trends. It is easy and convenient to unfold and store the movable partition wall by the strength of only one person.



Tightness

Multiple sealing strips are installed on the partition wall, so that the partition wall can effectively increase the sealing performance of the whole wall. The nodes use memory glue to maintain this characteristic and increase the sound insulation performance.
