Model No.: MQ-PARTITION
Brand: MAGIC CUBE
Warranty Service: 5 Years
After-sales Service: Online Technical Support, Return And Replacement, Other
Engineering Solution Capability: Total Solution For Projects, Others
Application Scenario: Hotel, Hall, Gym, Office Building, Mall, Home Office
Design Style: Contemporary, Scandinavian, Eclectic, Victorian, Traditional, Postmodern, Southwestern, Japanese, Modern, Mediterranean, Craftsman, Chinese, Minimalist, Coastal, Mid-Century Modern, French, Industrial, Rustic, Transitional, Midcentury, European, Farmhouse, Asian, Tropical
Place Of Origin: China
Model NO.: Movable Partitions
Type: Melamine MDF Panel, Fireproof PVC Board, Fabric
Application: Office, Hotel Banquet Hall, etc.
Main Material: Aluminum Frame and Track
Soundproof Mater: Rock Rool , Glass Wool
Soundproof Stc: 40dB-50dB
Dimensions: W700-1200mm, H2000-5200mm, Thickness 80-110mm
Stacking Way: Centre Partiting; Side Parking
Open Way: Sliding Partition
Ransport Package: Carton Paper Packaging, MDF Batten Cover Corners
Packaging: Carton Paper Packaging, MDF Batten Cover Corners
Productivity: 5000sq/Month
Transportation: Ocean
Place of Origin: CHINA
Supply Ability: 5000sq/Month
Certificate: CE
HS Code: 76101000
Port: SHNZHEN,GUANGZHOU
Payment Type: T/T,Others
Incoterm: FOB,CIF,EXW
The hotel banquet hall folding partitions for hall has a variety of finish options. Because of the different needs of customers, different venue spaces and the variety of finishes, each folding partitions for hall is different and very personalized. In addition to traditional materials such as plate hard packs and cloth leather soft packs, there are also new technical materials such as 3D printing and inkjet printing, so it can fully show the unique charm of your products.
Type | 65 type, 80 type, 100 type, ultra high 100 type. |
Finish | melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel |
Density | 28~32kg/m² |
STC | 40db-50db |
Dimensions | width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg |
Structure | 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing |
Panel Suspension | Top hunge system without the need for a floor track. |
Panel Width | Each panel 600mm-1200mm. |
Track | Aluminum OR Steel Track |
Roller on panel | Single or double roller. |
Panel Frames | Heavy-duty steel-gusseted aluminum inner frames reinforced with full height. |
Top&bottm seals | Top and bottom pressure retractable seals ensure effortless moved and locked. |
Module | 700mm - 1200mm maximum. |
Panel stacking | Numerous panel stacking options for complete flexibility. |
Panel face | MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc. |
Finishes | Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard |
Ultra high 100 type
Ultra-high detachable partition wall is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high detachable partition wall can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.
Features
Stacking Ways
Applications
When installing a hotel movable partition wall, it is necessary to survey the surrounding environment and measure the size of the installation site to understand the overall environment and obtain the appropriate height and partition range. In order to make the partition and the scene form a strong consistency, more fashionable and good collocation, showing a strong coordinated visual effect.
The movable partition walls of the hotel banquet hall have very strict control standards in terms of materials. In order to reduce the pollution output, the movable partition walls are made of environmentally friendly and lightweight materials. Because there are no harmful substances such as formaldehyde in the panels of the movable partition, the entire installation period is very short, and the entire installation project is completed very quickly. After installation, the venue and partition can be used immediately, saving time and labor costs. For the commercial building spaces with large passenger flow such as banquet hall hotels, event partitions can meet the requirements of hotel banquet halls in all aspects such as features, functions and advantages. necessary needs.
Different hotel banquet halls will also have different functions and purposes. When setting up meeting rooms in banquet halls, a single large space cannot meet the respective needs of multiple enterprises at the same time. It is divided into corresponding small spaces with activity partitions. As long as the partition wall is set up in advance and the corresponding table and chairs are placed on the same day, it is completed.
To create a high-end atmosphere of the banquet hall, the space must be open, but under the condition of limited economic budget, it is impossible to establish its open space, because it is impossible for most hotels to spend a lot of money on low utilization rates. in the banquet hall. In order to make better use of limited space resources, active partitions solve these problems to a large extent.
For folding patitions walls used in commercial spaces such as hotel banquet halls, in order to improve the viewing experience and support the design of various patterns and patterns on the partition, you can choose elements such as landscape paintings, portraits, and gorgeous portraits, because such a design It is more suitable for the luxurious style of hotel banquet halls and other places and is widely sought after. So how is such a partition made? Let me briefly introduce it below.
The folding patitions walls of the mural design is the same as other styles in terms of panel frame, internal expansion and filling, and the difference between them is the difference in the finish. To choose a good mural style, it is necessary to use fiber for the panel to do the basic work, and then make the pattern to be made with mural cloth according to the customer's overall partition size specifications, and make corresponding cuts according to the size of the drawing board and then outsource it to the fiberboard. The general practice is that the murals of each panel are inlaid into the aluminum-magnesium alloy frame, so that there will be a frame shape of one or two centimeters wide around the mural.
