Model No.: MQ-PARTITION
Main Application: Commercial Furniture
Types Of: Office Furniture
Whether To Support Mail Order Packaging (special Packaging For Cross-border E-commerce): Y
Product Description
When installing and operating the Movable Wall ,Moveable Wall, all movements should be gentle and pay attention to safety. Stand upright facing the partition wall, grab both sides of the Movable Wall ,Moveable Wall with both hands and gently pull the partition wall along the track. When the movable partition wall is pushed to the intersection, you should pay attention to the direction of the rail, and then nudge the partition wall to the position where it should be placed.
Specifications
Type | 65 type, 80 type, 100 type, ultra high 100 type. |
Finish | melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel |
Density | 28~32kg/m² |
STC | 40db-50db |
Dimensions | width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg |
Structure | 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing |
Panel Suspension | Top hunge system without the need for a floor track. |
Panel Width | Each panel 600mm-1200mm. |
Track | Aluminum OR Steel Track |
Roller on panel | Single or double roller. |
Panel Frames | Heavy-duty steel-gusseted aluminum inner frames reinforced with full height. |
Top&bottm seals | Top and bottom pressure retractable seals ensure effortless moved and locked. |
Module | 700mm - 1200mm maximum. |
Panel stacking | Numerous panel stacking options for complete flexibility. |
Panel face | MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc. |
Finishes | Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard |
Ultra high 100 type
Ultra-high Moveable Wall is designed for Moveable Wall as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high partition can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.
Features
Stacking Ways
Applications
The ultra-high movable partition is a kind of Movable Partition Wall, also known as the partition wall, which is a non-load-bearing component that separates the interior space of the building. When you don't need to use it, you can fold it and put it aside to make the combined space appear wider and larger. The movable partition has the characteristics of easy movement, simple operation, high Sound Insulation and fire protection, etc. It is especially suitable for hotels and Space separation in large buildings such as banquet halls. The design of this movable partition is equipped with a vertical compression fitting device to keep the partition in place very securely.
1. It supports partial disassembly and assembly, which can be reused many times. The material of the partition wall system adopts polymer technology materials, and it has the functions of fireproof, sound insulation and heat insulation. Because it is a green and environmentally friendly building material, it has a long service life. The materials for installing movable partition walls are cheaper and more durable than installing other forms of partition materials. Therefore, the activity partition is more cost-effective, and it is suitable for use in banquet halls, hotels and other places.
2. In a hotel or banquet hall, customer groups and customer needs determine the area of the separated space. In order to meet the office needs of enterprises in all walks of life at the same time, the large space with a single function is divided into multiple small spaces with different areas. Improve space utilization and flexibly change the size of the space.
3. The ultra-high Movable Partition Wall is surrounded by a double-layer aluminum alloy frame with a thickness of about 100mm. Various methods such as oxidation and electrophoresis can be used according to customer requirements. This kind of movable partition wall adopts heavy-duty track, and the number of wheel rolling and hanging wheel sliding can reach 100,000 times. The partition wall is made of fire-proof and moisture-proof materials, which has a good sound insulation effect. In normal use, only one person can easily push the huge Ultra-high Partition Wall. Multiple small spaces used by many people can be arranged in a very short time, which is efficient and labor-saving. In today's fast-paced society, time is money. Reasonably manage time and improve work efficiency efficiently, which is why movable partition walls are so popular and accepted.
Product Categories : Hall Sliding Partition
