Model No.: MQ-PARTITION
Brand: MAGIC CUBE
After-sales Service: Online Technical Support, Return And Replacement, Other
Engineering Solution Capability: Total Solution For Projects, Others
Application Scenario: Hotel, Villa, Office Building, Workshop, Home Office, Gym, Hall, Mall
Design Style: Contemporary, Scandinavian, Eclectic, Victorian, Traditional, Postmodern, Southwestern, Japanese, Modern, Mediterranean, Craftsman, Chinese, Minimalist, Coastal, Mid-Century Modern, French, Industrial, Rustic, Transitional, Midcentury, European, Tropical, Farmhouse, Asian
Place Of Origin: China
Model NO.: Movable Partitions
Type: Melamine MDF Panel, Fireproof PVC Board, Fabric
Application: Office, Hotel Banquet Hall, etc.
Main Material: Aluminum Frame and Track
Soundproof Mater: Rock Rool , Glass Wool
Soundproof Stc: 40dB-50dB
Dimensions: W700-1200mm, H2000-5200mm, Thickness 80-110mm
Stacking Way: Centre Partiting; Side Parking
Open Way: Sliding Partition
Ransport Package: Carton Paper Packaging, MDF Batten Cover Corners
Packaging: Carton Paper Packaging, MDF Batten Cover Corners
Productivity: 5000sq/Month
Transportation: Ocean
Place of Origin: CHINA
Supply Ability: 5000sq/Month
Certificate: CE
HS Code: 76101000
Port: SHENZHEN,GUANGZHOU
Payment Type: T/T
Incoterm: FOB,CIF,EXW
The Moveable Partition Wall used in each place is completely different. The Moveable Partition Wall ordered in this place can only be used in this place, because the precise size data of the site size needs to be recorded before the movable partition wall panel is made, and you can choose by yourself. Plates, finishes and colours. There are four types of our movable partition walls, 65 type, 80 type, 100 type and super high 100 type. Different types of partition walls are selected according to different places, and the thickness is customized according to the height and customer needs.
Specifications
| Type | 65 type, 80 type, 100 type, ultra high 100 type. |
| Finish | melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel |
| Density | 28~32kg/m² |
| STC | 40db-50db |
| Dimensions | width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg |
| Structure | 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing |
| Panel Suspension | Top hunge system without the need for a floor track. |
| Panel Width | Each panel 600mm-1200mm. |
| Track | Aluminum OR Steel Track |
| Roller on panel | Single or double roller. |
| Panel Frames | Heavy-duty steel-gusseted aluminum inner frames reinforced with full height. |
| Top&bottm seals | Top and bottom pressure retractable seals ensure effortless moved and locked. |
| Module | 700mm - 1200mm maximum. |
| Panel stacking | Numerous panel stacking options for complete flexibility. |
| Panel face | MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc. |
| Finishes | Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard |
Ultra high 100 type
Ultra-high Moveable Wall is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high Moveable Wall can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.
Features
Stacking Ways
Applications
At present, Movable Wall ,Moveable Wall are becoming more and more common in our lives, especially in some places with relatively large spaces, partitions can play a great role. Make this space layout simple.
What are the characteristics of movable partition
1. Freedom. The Movable Wall ,Moveable Wall can be used freely, and it can be expanded or reduced according to the size of different areas of the space and the needs of customers, which is very convenient to use.
2. The movable partition can separate the space at will, and at the same time can ensure the privacy of the user. With a private space, life will become more convenient.
3. Then, the Sound Insulation effect of this partition is very good, and it also has a certain degree of heat insulation.
4. In general, the appearance design of the movable partition is very fashionable and simple, so no matter where it is placed, it can play a certain decorative role. This partition is widely used in hotels, guesthouses, banquet halls and other occasions, because it is very convenient to install and use, and the decorative effect is very good.
5. Although this partition can be moved, its stability is very strong. As long as it is properly installed, it will never shift its position.
6. The installation of the mobile partition is very simple and convenient, and there is no need to install the track on the ground. The track of this partition is installed on the ceiling. In this way, it will not look so complicated on the ground, and once the mobile partition is installed, not only can it be used quickly, but also it is not easy to swing, so it can be used with confidence.
