Brand: MAGIC CUBE
Main Application: Commercial Furniture
Types Of: Office Furniture
Whether To Support Mail Order Packaging (special Packaging For Cross-border E-commerce): Y
Transportation: Ocean
Place of Origin: CHINA
Certificate: CE
HS Code: 76101000
Payment Type: T/T,Others
Incoterm: FOB,CIF,EXW
floor to ceiling movable walls is a Movable Wall with general wall functions that can divide large space into small space or connect small space into large space at any time according to needs. It can play a role of multiple functions in one hall or one room. The acoustic movable walls brings great convenience to people's work. For example, you can fold it on one side when you need it, so that the two spaces are temporarily joined to make them appear larger, which is convenient for temporary departmental meetings.
Specifications
| Type | 65 type, 80 type, 100 type, ultra high 100 type. |
| Finish | melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel |
| Density | 28~32kg/m² |
| STC | 40db-50db |
| Dimensions | width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg |
| Structure | 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing |
| Panel Suspension | Top hunge system without the need for a floor track. |
| Panel Width | Each panel 600mm-1200mm. |
| Track | Aluminum OR Steel Track |
| Roller on panel | Single or double roller. |
| Panel Frames | Heavy-duty steel-gusseted aluminum inner frames reinforced with full height. |
| Top&bottm seals | Top and bottom pressure retractable seals ensure effortless moved and locked. |
| Module | 700mm - 1200mm maximum. |
| Panel stacking | Numerous panel stacking options for complete flexibility. |
| Panel face | MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc. |
| Finishes | Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard |
Ultra high 100 type
Ultra-high floor to ceiling movable walls is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high partition can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.
Features
Stacking Ways
Applications
How to Install moveable internal walls
1. The size of the upper track box of the mobile partition should be guaranteed to be 12cm high and 9cm wide. Install the track in the track box to hang the mobile partition on the track.
What are the characteristics of the acoustic folding walls, how to install the movable partition
2. Under normal circumstances, it is more suitable for the partition fan of the mobile partition to be about 80 cm by 200 cm. The door of this structure is relatively stable, and the appearance will be more beautiful, so the width and height of the mobile partition must maintain the golden size.
3. When installing moveable internal walls, it is best not to use mobile partitions that fall to the top, because the swing range is too large when pushing and pulling, and the use of a long time will cause the mobile partitions to be easily deformed, making it impossible to open the partition door panel. This affects the use of partitions.
4. When installing the mobile partition track, the upper track should be fixed, and then the upper track should be installed with the gravity cone and the two ends and midpoints of the upper track. Be sure to pay attention to placing vertical lines at both ends of the track, and fix the lower track with three points to ensure that the upper and lower tracks are completely parallel, so that the partition can be in the best state.
The above content is a general introduction to the characteristics of acoustic folding walls and how to install them. Finally, remind everyone that the choice of mobile partition must use formal materials to ensure safety and quality.
