HomeProductsMovable Wallhotel soundproof wooden movable divider wall
hotel soundproof wooden movable divider wall
  • hotel soundproof wooden movable divider wall
  • hotel soundproof wooden movable divider wall
  • hotel soundproof wooden movable divider wall
  • hotel soundproof wooden movable divider wall

hotel soundproof wooden movable divider wall

$89.99 - 129.99 /Square Meter
Sound-absorbing board varieties:
Share:
  • Product Description
< >
Overview
Product Attributes

Brand: MAGIC CUBE

Main Application: Commercial Furniture

Types Of: Office Furniture

Whether To Support Mail Order Packaging (special Packaging For Cross-border E-commerce): Y

Supply Ability & Additional Information

Transportation: Ocean

Place of Origin: CHINA

Certificate: CE

HS Code: 76101000

Payment Type: T/T,Others

Incoterm: FOB,CIF,EXW

Packaging & Delivery
Selling Units:
Square Meter










Product Structure


Electrically Operated Movable Walls Hotel Partition Wall Panels Movable Partitions Movable Partition Walls
Electrically Operated Movable Walls Hotel Partition Wall Panels Movable Partitions Movable Partition Walls



Panel Suspension  Top hunge system without the need for a floor track.
Panel Width Each panel 600mm-1200mm.
Track Aluminum OR Steel Track
Roller on panel Single or double  roller.
Panel Frames  Heavy-duty steel-gusseted aluminum inner frames reinforced with  full height.
Top&bottm seals Top and bottom pressure retractable seals ensure effortless moved and locked.
Module 700mm - 1200mm maximum.
Panel stacking Numerous panel stacking options for complete flexibility.
Panel face  MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard




Electrically Operated Movable Walls Hotel Partition Wall Panels Movable Partitions Movable Partition Walls

Ultra high 100 type

    Ultra-high partition movable walls is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high partition can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.

Features

  • Load bearing of each meter is more than 2000 KGS
  • Each pulley bearing more than 1500 KGS
  • Easily moved even being pushed at waist-high
  • The panel can make a turn automatically as sliding in the straight rail


Electrically Operated Movable Walls Hotel Partition Wall Panels Movable Partitions Movable Partition Walls

Electrically Operated Movable Walls Hotel Partition Wall Panels Movable Partitions Movable Partition Walls

Stacking Ways

Electrically Operated Movable Walls Hotel Partition Wall Panels Movable Partitions Movable Partition WallsApplications

Electrically Operated Movable Walls Hotel Partition Wall Panels Movable Partitions Movable Partition Walls
Electrically Operated Movable Walls Hotel Partition Wall Panels Movable Partitions Movable Partition Walls
Electrically Operated Movable Walls Hotel Partition Wall Panels Movable Partitions Movable Partition Walls
Electrically Operated Movable Walls Hotel Partition Wall Panels Movable Partitions Movable Partition Walls


Electrically Operated Movable Walls Hotel Partition Wall Panels Movable Partitions Movable Partition Walls

How to installation moveable panel walls track

Suspended track: The fixed way of the suspended guide is to install a pulley on the top surface of the partition door panel, which is connected to the track suspended from the ceiling. The type of track and pulley should be selected according to the size of the bearing weight. For heavy-duty movable partition walls, the rails are screwed or welded to the steel frame.

According to the specific weight of the track and the partition fan, install the pulley in advance and reserve the opening of the track.


1. Install the moveable panel walls panel

According to the installation method, accurately draw the pulley line on each panel, and then fix the fixing frame of the pulley on the upper or lower stile of the partition fan with screws; then put the panels into the track one by one, and adjust each panel to be perpendicular to the The ground, and the push-pull rotation is flexible, and finally each fan is connected and fixed. Usually, the adjacent panels are connected by hinges


2. Install movable partition door panels

Mark the pulley placement line on each acoustic moveable walls door panel, and then fix the pulley's fixing frame on the upper or lower column of the partition fan with screws; The condition of each door panel, make them perpendicular to the ground, after ensuring that they can be pushed flexibly, connect and fix each door panel, and connect the adjacent panels with hinges.



3. Finishes

 According to the different needs of customers and different styles of venues, different color styles can be selected; after the finishing is done, paint finishing or edge trimming can be carried out, and the finishing processing of the hotel should be carried out according to the second standard requirements.


4. Debug:

After all the door panels of the acoustic moveable walls are installed, the panel height, sealing and other details should be debugged. After the debugging, the site should be cleaned up, and the installation work will be completed.






























Product Categories : Movable Wall
