High Quality Office soundproof movable panels



Product Structure






Panel Suspension	Top hunge system without the need for a floor track.
Panel Width	Each panel 600mm-1200mm.
Track	Aluminum OR Steel Track
Roller on panel	Single or double  roller.
Panel Frames	Heavy-duty steel-gusseted aluminum inner frames reinforced with  full height.
Top&bottm seals	Top and bottom pressure retractable seals ensure effortless moved and locked.
Module	700mm - 1200mm maximum.
Panel stacking	Numerous panel stacking options for complete flexibility.
Panel face	MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes	Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard



Ultra high 100 type

    office moveable walls is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. office moveable walls is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high partition can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.

Features

• Load bearing of each meter is more than 2000 KGS
• Each pulley bearing more than 1500 KGS
• Easily moved even being pushed at waist-high
• The panel can make a turn automatically as sliding in the straight rail

Stacking Ways

Applications

What are the characteristics of movable partition walls?

A soundproof movable panels is a Movable Wall that divides a large space into small spaces or connects small spaces into large spaces at any time according to needs, and has the function of a general wall. It has the following characteristics:

1. Suspension without ground rails: the floor has no rails, just install the rails on the ceiling;

 2. Stable and safe: it is stable and reliable after partitioning, and it is not easy to swing;

3. Sound Insulation and environmental protection: the sound insulation effect is good, and the sound insulation coefficient can be adjusted Up to 50dB; 4. Heat insulation and energy saving: excellent heat insulation performance, according to different occupancy rates, the large space is divided into small spaces to reduce the power consumption of air conditioning; Beautiful and elegant: the surface can be decorated arbitrarily, and the decorative effect can be unified with the interior; 7. Flexible retraction: the partition can be retracted freely and pushed flexibly, and one person can complete the whole process of partition; 8. Convenient collection: when closing the board, the partition can be Hidden in a special storage cabinet, it does not affect the overall appearance; 9. Wide application: a wide range of applications, can be used in conference halls, exhibition halls, restaurants, high-clean factories and rooms and other places;
