Thermal Insulation movable partition walls for office

$89.99 - 129.99 /Square Meter
Sound-absorbing board varieties:
Share:
  • Product Description
Overview
Product Attributes

Model No.MA-PARTITION

BrandMAGIC CUBE

Warranty Service5 Years

After-sales ServiceOnline Technical Support, Return And Replacement, Other

Engineering Solution CapabilityTotal Solution For Projects, Others

Application ScenarioHotel, Gym, Mall, Hall, Home Office, Workshop, Home Bar, Office Building, Villa

Design StyleContemporary, Scandinavian, Eclectic, Victorian, Traditional, Postmodern, Southwestern, Japanese, Modern, Mediterranean, Craftsman, Chinese, Minimalist, Coastal, Mid-Century Modern, French, Industrial, Rustic, Transitional, Midcentury, European, Tropical, Farmhouse, Asian

Place Of OriginChina

Model NO.Movable Partitions

TypeMelamine MDF Panel, Fireproof PVC Board, Fabric

ApplicationOffice, Hotel Banquet Hall, etc.

Main MaterialAluminum Frame and Track

Soundproof MaterRock Rool , Glass Wool

Soundproof Stc40dB-50dB

DimensionsW700-1200mm, H2000-5200mm, Thickness 80-110mm

Stacking WayCentre Partiting; Side Parking

Open WaySliding Partition

Ransport PackageCarton Paper Packaging, MDF Batten Cover Corners

Supply Ability & Additional Information

PackagingCarton Paper Packaging, MDF Batten Cover Corners

Productivity5000sq/Month

TransportationOcean

Place of OriginCHINA

Supply Ability5000sq/Month

CertificateCE

HS Code76101000

PortSHENZHEN,GUANGZHOU

Payment TypeT/T,Others

IncotermFOB,CIF,EXW

Packaging & Delivery
Selling Units:
Square Meter
Package Type:
Carton Paper Packaging, MDF Batten Cover Corners
Product Description


The sliding folding partition walls used in each place is completely different. The partition wall ordered in this place can only be used in this place, because the precise size data of the site size needs to be recorded before the movable partition wall panel is made, and you can choose by yourself. Plates, finishes and colours. There are four types of our sliding folding partition walls, 65 type, 80 type, 100 type and super high 100 type. Different types of partition walls are selected according to different places, and the thickness is customized according to the height and customer needs.


Specifications

Type 65 type, 80 type, 100 type, ultra high 100 type.
Finish melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel
Density  28~32kg/m²
STC 40db-50db
Dimensions width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg
Structure 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing


Product Structure


Interior Decoration Acoustical Wall Movable Partition Wall Systems for Multi-Function Hall
Interior Decoration Acoustical Wall Movable Partition Wall Systems for Multi-Function Hall



Panel Suspension  Top hunge system without the need for a floor track.
Panel Width Each panel 600mm-1200mm.
Track Aluminum OR Steel Track
Roller on panel Single or double  roller.
Panel Frames  Heavy-duty steel-gusseted aluminum inner frames reinforced with  full height.
Top&bottm seals Top and bottom pressure retractable seals ensure effortless moved and locked.
Module 700mm - 1200mm maximum.
Panel stacking Numerous panel stacking options for complete flexibility.
Panel face  MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard




Interior Decoration Acoustical Wall Movable Partition Wall Systems for Multi-Function Hall

Ultra high 100 type

    Ultra-high soundproof movable panels is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high soundproof movable panels can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.

Features

  • Load bearing of each meter is more than 2000 KGS
  • Each pulley bearing more than 1500 KGS
  • Easily moved even being pushed at waist-high
  • The panel can make a turn automatically as sliding in the straight rail


Interior Decoration Acoustical Wall Movable Partition Wall Systems for Multi-Function Hall

Interior Decoration Acoustical Wall Movable Partition Wall Systems for Multi-Function Hall

Stacking Ways

Interior Decoration Acoustical Wall Movable Partition Wall Systems for Multi-Function HallApplications

Interior Decoration Acoustical Wall Movable Partition Wall Systems for Multi-Function Hall
Interior Decoration Acoustical Wall Movable Partition Wall Systems for Multi-Function Hall
Interior Decoration Acoustical Wall Movable Partition Wall Systems for Multi-Function Hall
Interior Decoration Acoustical Wall Movable Partition Wall Systems for Multi-Function Hall


Interior Decoration Acoustical Wall Movable Partition Wall Systems for Multi-Function Hall

Now the office moveable walls are more and more widely used in the market, this is because the movable partition has several prominent features compared with the general fixed traditional partition wall:

1. Practicality: Generally, the hotel lobby or box should often adjust the space and area according to the number of diners, and the movable partition

The advantage is precisely that it can be flexibly divided into usable spaces. Expanding the telescopic mechanism is to fix the partition wall, and when it is stored, it can be restored to a large space as a whole.

2. The Sound Insulation effect is good, the aluminum-magnesium frame is an aluminum-magnesium alloy frame, the middle is filled with sound insulation cotton, and the two sides are packaged with the upper board. The panel contact surface is intentionally uneven.

3. There are various styles of beautiful office moveable walls, and the finishes of movable partition walls are various, such as paint-free boards, fire-proof boards, hard packs, soft packs and murals, etc. Various needs are made according to customer needs. And it is easier and more accurate to complete the overall matching according to the required installation site.

The hanging wheel of the movable partition is made of PTFE material, which is super wear-resistant, corrosion-resistant, acid and alkali resistant. Each hanging wheel is composed of two wheels with reinforced steel rings. It glides smoothly and smoothly on the track, and the gliding process is silent and noiseless.

Each partition will be equipped with one or two hanging wheels, which are equipped with delicate bearings, which can make smooth turns at 90 degrees, 180 degrees, 360 degrees and other specific angles without the need for steering gear. The retractor in the partition can be moved up and down by shaking hands, and each partition wall can also be fixed individually. Each partition wall is equipped with a fast expansion and sealing system, which makes the partition fast and is called a solid wall. , Shake the joystick to make the P1 board extend up and down, left and right, and the P2 board extend up and down, thus forming a complete partition wall.

The movable partition wall is suitable for various industries, including the banquet halls and conference centers of the world's top hotels, convention and exhibition centers, restaurants converted into commercial offices, educational and religious places, etc. We fully meet the needs of users, and the partitions produced are strictly implemented in accordance with national standards, bringing high-quality and high-taste enjoyment to the architectural decoration market. Keeping up with the trend of the times, we launch an updated product series, which is suitable for the function and beauty of space decoration, and adds a higher level of taste to the decorative life of modern buildings.
