Model No.: MQ-PARTITION
Brand: MAGIC CUBE
Warranty Service: 5 Years
After-sales Service: Online Technical Support, Return And Replacement, Other
Engineering Solution Capability: Total Solution For Projects, Others
Application Scenario: Hotel, Office Building, Mall, Workshop, Gym, Home Office
Design Style: Contemporary, Postmodern, Craftsman, Traditional, Mediterranean, Mid-Century Modern, Modern, Coastal, Transitional, Minimalist, Rustic, Tropical, Industrial, Victorian, Midcentury, Asian, Eclectic, Japanese, Farmhouse, Scandinavian, Southwestern, Chinese
Place Of Origin: China
Model NO.: Movable Partitions
Type: Melamine MDF Panel, Fireproof PVC Board, Fabric
Application: Office, Hotel Banquet Hall, etc.
Main Material: Aluminum Frame and Track
Soundproof Mater: Rock Rool , Glass Wool
Soundproof Stc: 40dB-50dB
Dimensions: W700-1200mm, H2000-5200mm, Thickness 80-110mm
Stacking Way: Centre Partiting; Side Parking
Open Way: Sliding Partition
Ransport Package: Carton Paper Packaging, MDF Batten Cover Corners
Packaging: Carton Paper Packaging, MDF Batten Cover Corners
Productivity: 5000sq/Month
Transportation: Ocean
Place of Origin: CHINA
Supply Ability: 5000sq/Month
Certificate: CE
HS Code: 76101000
Port: SHENZHEN,GUANGZHOU
Payment Type: T/T,Others
Incoterm: FOB,CIF,EXW
The movable partition wall needs professionals to install, but in daily use, only one person can easily push and pull the partition wall door panel, which greatly saves manpower and material resources. Set rules and simple system assembly method, no gas and polluting waste will be released after construction.
Specifications
| Type | 65 type, 80 type, 100 type, ultra high 100 type. |
| Finish | melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel |
| Density | 28~32kg/m² |
| STC | 40db-50db |
| Dimensions | width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg |
| Structure | 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing |
| Panel Suspension | Top hunge system without the need for a floor track. |
| Panel Width | Each panel 600mm-1200mm. |
| Track | Aluminum OR Steel Track |
| Roller on panel | Single or double roller. |
| Panel Frames | Heavy-duty steel-gusseted aluminum inner frames reinforced with full height. |
| Top&bottm seals | Top and bottom pressure retractable seals ensure effortless moved and locked. |
| Module | 700mm - 1200mm maximum. |
| Panel stacking | Numerous panel stacking options for complete flexibility. |
| Panel face | MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc. |
| Finishes | Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard |
Ultra high 100 type
Ultra-high Movable Partition is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high partition can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.
Features
Stacking Ways
Applications
The ultra-high movable partition wall used in large and important places such as hotel banquet halls and conference halls refers to the space specially used to separate the interior, with stronger and more flexible applications, such as partition walls, partitions, movable display boards, movable screens, mobile Partitions, mobile screens, mobile soundproof walls, etc., movable partitions are easy to install and reusable. The large space of the site is divided into several small spaces, and finally a large space can be combined. The function of the movable partition wall is the same as that of the general wall, and it can play a role of multi-purpose in one hall and one room.
The movable partition wall has an advanced professional configuration system, the movable partition can automatically turn, and the guide rail is equipped with a professional guide block.
Push and pull are not blocked, smooth and not stuck.
The movable partition wall is suspended on aluminum rails and equipped with multi-directional wheels. The movable partition wall is mounted on the ceiling, suspended on aluminum rails, and also equipped with multi-directional wheels.
Precautions：
1. High-quality hanging wheels: The ultra-high type movable partition door panel is large and heavy. It must be a steel hanging wheel with a suitable type and bearing to ensure its safety.
2. Arc-shaped track: Ultra-high door panels generally require corners, and special customized arc-shaped corners need to be used. In order to ensure that the sliding door panel is smooth and easy to use, special customized steel elbows are required.
3. Hotel ultra-high-type partition storage: Ultra-high-type movable partition walls generally have storage rooms, and the panels need to be tilted during storage, so that it is easy to pick and place next time.
Storage method of ultra-high movable partition: The ultra-high movable partition wall generally has a storage room, which needs to be tilted for storage, which is convenient for next use and convenient access.
