Model No.: MQ-PARTITION
Brand: MAGIC CUBE
Warranty Service: 5 Years
After-sales Service: Online Technical Support, Return And Replacement, Other
Engineering Solution Capability: Total Solution For Projects, Others
Application Scenario: Hotel, Office Building, Workshop, Gym, Hall, Mall, Home Office
Design Style: Contemporary, Scandinavian, Eclectic, Victorian, Traditional, Southwestern, Japanese, Postmodern, Modern, Mediterranean, Craftsman, Chinese, Minimalist, Coastal, Mid-Century Modern, French, Industrial, Rustic, Transitional, Midcentury, European, Farmhouse, Asian, Tropical
Place Of Origin: China
Model NO.: Movable Partitions
Type: Melamine MDF Panel, Fireproof PVC Board, Fabric
Application: Office, Hotel Banquet Hall, etc.
Office, Hotel Banquet Hall, Etc.: Aluminum Frame and Track
Soundproof Mater: Rock Rool , Glass Wool
Soundproof Stc: 40dB-50dB
Dimensions: W700-1200mm, H2000-5200mm, Thickness 80-110mm
Stacking Way: Centre Partiting; Side Parking
Open Way: Sliding Partition
Ransport Package: Carton Paper Packaging, MDF Batten Cover Corners
Packaging: Carton Paper Packaging, MDF Batten Cover Corners
Productivity: 5000sq/Month
Transportation: Ocean
Place of Origin: CHINA
Supply Ability: 5000sq/Month
Certificate: CE
HS Code: 76101000
Port: SHENZHEN,GUANGZHOU
Payment Type: T/T,Others
Incoterm: FOB,CIF,EXW
divisions movable walls are generally used in public workplaces such as banquet halls and exhibitions. It must be possible to create an excellent customer's activity space at the same time according to the actual situation, so that there are many business-friendly functions that can be next door. In order to avoid the intermittent waiting of scratches or back shadows during transportation, After the movable partition wall is sent to the installation site, finishing processing will be carried out.
| Type | 65 type, 80 type, 100 type, ultra high 100 type. |
| Finish | melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel |
| Density | 28~32kg/m² |
| STC | 40db-50db |
| Dimensions | width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg |
| Structure | 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing |
| Panel Suspension | Top hunge system without the need for a floor track. |
| Panel Width | Each panel 600mm-1200mm. |
| Track | Aluminum OR Steel Track |
| Roller on panel | Single or double roller. |
| Panel Frames | Heavy-duty steel-gusseted aluminum inner frames reinforced with full height. |
| Top&bottm seals | Top and bottom pressure retractable seals ensure effortless moved and locked. |
| Module | 700mm - 1200mm maximum. |
| Panel stacking | Numerous panel stacking options for complete flexibility. |
| Panel face | MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc. |
| Finishes | Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard |
Ultra high 100 type
Ultra-high soundproof portable partition walls is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high office moveable walls can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.
Features
Stacking Ways
Applications
The movable partition wall is like a door, unfold it when you need it, and store it when you don't need it, because the movable partition wall has a beautiful appearance and is integrated with the interior decoration.
Precautions：
1. High-quality hanging wheels: The ultra-high type soundproof movable panels door panel is large and heavy. It must be a steel hanging wheel with a suitable type and bearing to ensure its safety.
2. Arc-shaped track: Ultra-high door panels generally require corners, and special customized arc-shaped corners need to be used. In order to ensure that the sliding door panel is smooth and easy to use, special customized steel elbows are required.
3. Hotel ultra-high-type partition storage: Ultra-high-type sliding folding partition walls generally have storage rooms, and the panels need to be tilted during storage, so that it is easy to pick and place next time.
Storage method of ultra-high movable partition: The ultra-high movable partition wall generally has a storage room, which needs to be tilted for storage, which is convenient for next use and convenient access.
4. Regarding the storage room: The storage room should centrally store the door panels, and the bearing capacity is large, so special reinforcement is required when welding the rails to enhance safety.
