highly efficient movable sound partition walls

$89.99 - 129.99 /Square Meter
Payment Type:
T/T
Incoterm:
FOB,CIF,EXW
Min. Order:
20 Square Meter
Transportation:
Ocean
Port:
GUANGZHOU,SHENZHEN
Share:
  • Product Description
Overview
Product Attributes

Model No.MQ-PARTITION

BrandMAGIC CUBE

Warranty Service5 Years

After-sales ServiceOnline Technical Support, Return And Replacement

Engineering Solution CapabilityTotal Solution For Projects

Application ScenarioHotel, Villa, Hall, Gym

Design StyleContemporary, Scandinavian, Eclectic, Victorian, Traditional, Postmodern, Southwestern, Japanese, Modern, Mediterranean, Craftsman, Chinese

Place Of OriginChina

Model NO.Movable Partitions

TypeMelamine MDF Panel, Fireproof PVC Board, Fabric

ApplicationOffice, Hotel Banquet Hall, etc.

Main MaterialAluminum Frame and Track

Soundproof MaterRock Rool , Glass Wool

Soundproof Stc40dB-50dB

Supply Ability & Additional Information

PackagingCarton Paper Packaging, MDF Batten Cover Corners

Productivity5000sq/Month

TransportationOcean

Place of OriginCHINA

Supply Ability5000sq/Month

CertificateCE

HS Code76101000

PortGUANGZHOU,SHENZHEN

Payment TypeT/T

IncotermFOB,CIF,EXW

Packaging & Delivery
Selling Units:
Square Meter
Package Type:
Carton Paper Packaging, MDF Batten Cover Corners
Product Description


Movable Divider Wall are widely used for installation in various places, such as different places, different places, etc. , you need to know in detail the height and length of the customer at any location and the needs of the partition wall to design the installation plan of the Movable Divider Wall size. The biggest feature of the movable partition wall is that it can be freely recombined into the required space. Most likely the installation was successful.



Specifications

Type 65 type, 80 type, 100 type, ultra high 100 type.
Finish melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel
Density  28~32kg/m²
STC 40db-50db
Dimensions width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg
Structure 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing



Product Structure


High Sound Insulation Operable Partition Sheets Folding Partition Wall Systems for Office or Meeting Room
High Sound Insulation Operable Partition Sheets Folding Partition Wall Systems for Office or Meeting Room



Panel Suspension  Top hunge system without the need for a floor track.
Panel Width Each panel 600mm-1200mm.
Track Aluminum OR Steel Track
Roller on panel Single or double  roller.
Panel Frames  Heavy-duty steel-gusseted aluminum inner frames reinforced with  full height.
Top&bottm seals Top and bottom pressure retractable seals ensure effortless moved and locked.
Module 700mm - 1200mm maximum.
Panel stacking Numerous panel stacking options for complete flexibility.
Panel face  MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard




High Sound Insulation Operable Partition Sheets Folding Partition Wall Systems for Office or Meeting Room

Ultra high 100 type

    Ultra-high Soundproof Movable Walls is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Soundproof Movable Walls is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high partition can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.

Features

  • Load bearing of each meter is more than 2000 KGS
  • Each pulley bearing more than 1500 KGS
  • Easily moved even being pushed at waist-high
  • The panel can make a turn automatically as sliding in the straight rail


High Sound Insulation Operable Partition Sheets Folding Partition Wall Systems for Office or Meeting Room

High Sound Insulation Operable Partition Sheets Folding Partition Wall Systems for Office or Meeting Room

Stacking Ways

High Sound Insulation Operable Partition Sheets Folding Partition Wall Systems for Office or Meeting RoomApplications

High Sound Insulation Operable Partition Sheets Folding Partition Wall Systems for Office or Meeting Room
High Sound Insulation Operable Partition Sheets Folding Partition Wall Systems for Office or Meeting Room
High Sound Insulation Operable Partition Sheets Folding Partition Wall Systems for Office or Meeting Room
High Sound Insulation Operable Partition Sheets Folding Partition Wall Systems for Office or Meeting Room


High Sound Insulation Operable Partition Sheets Folding Partition Wall Systems for Office or Meeting Room

The Ultra-high Partition Wall is to divide a large space with a single function into a space with multiple functions at the same time, and then divide the indoor space vertically. In order to meet the various requirements of customers at the same time, this kind of ultra-high movable partition wall is often used by hotels. This form of division is the most commonly used in interior design. It is essentially a unified form but not identical. It can be divided into multiple spaces with different or equal areas, as long as they need to be separated by movable partitions You can use this ultra-high movable partition wall to use it into multiple small spaces.

Our Ultra-High Partition Wall are stylish and generous in style and design, and we will formulate and modify construction plans according to customers' ideas and needs until customers are satisfied. Our ultra-high movable partition wall is a new type of office facility that divides a large space into many flexible and convenient small event spaces. The product style is beautiful and diverse, the assembly is flexible and simple, fireproof, scratchproof and soundproof. The small space is flexibly divided according to the needs of use, and any adult can easily move and operate. Ultra-high movable partition walls are often used in various multi-functional restaurants, hotel lobbies, hotel conference rooms and banquet halls and other architectural decoration spaces to help buildings make rational use of space.



Features:

1. The height of the partition door is sometimes as high as 15 meters. When people push the partition door, the height that can be reached by the human hand is limited. Even such a high partition wall door can use the movable partition wall smoothly by relying on the strength of one person.

2. The material of the partition wall door panel is smooth and not thorny, and it is easy to clean and wipe off the stains. Use a rag or a foldable long mop to simply wet the surface with clean water to wipe the dust and dirt on the surface. It is easy to wipe off with a light wipe.

3. The ultra-high partition wall can not only prevent fire and heat insulation, but also has a Sound Insulation coefficient of up to 50dB, which means that it can isolate the voice of ordinary people. Someone is talking in a meeting next door. Automatically becomes smaller or even disappears inaudible.

4. Our ultra-high partition door panels do not have wheels, and are driven entirely by the rails above the ceiling. This way no marks will be left on the floor.

5. In order to better meet the customization requirements of each customer, our door has experienced professional designers to design construction plans for customers, combining the colors and styles selected by customers and the data that have been measured on the customer site and the needs of customers. Integrate and summarize ZAAI to design a construction plan that satisfies the customer.
