MDF Wooden acoustic sound partition wall

$89.99 - 129.99 /Square Meter
Sound-absorbing board varieties:
Share:
  • Product Description
Overview
Product Attributes

Model No.MQ-PARTITION

BrandMAGIC CUBE

Warranty Service5 Years

After-sales ServiceOnline Technical Support, Return And Replacement

Engineering Solution CapabilityTotal Solution For Projects

Application ScenarioHotel, Home Bar, Hall, Gym, Workshop, Office Building

Design StyleContemporary, Farmhouse, Rustic, Mid-Century Modern, Chinese, Traditional, Scandinavian, European, French, Modern, Postmodern, Asian, Transitional, Eclectic, Tropical, Minimalist, Mediterranean, Southwestern

Place Of OriginChina

Model NO.series 85 partition walls

CertificationISO9001

Materialaluminum

Thickness85mm

FoldingFolding Partition

Surface FinishingFabric with MDF Board

Supply Ability & Additional Information

PackagingCarton Paper Packaging, MDF Batten Cover Corners

Productivity5000sq/Month

TransportationOcean

Place of OriginCHINA

Supply Ability5000sq/Month

CertificateCE

HS Code76101000

PortSHENZHEN,GUANGZHOU

Payment TypeT/T

IncotermFOB,CIF,EXW

Packaging & Delivery
Selling Units:
Square Meter
Package Type:
Carton Paper Packaging, MDF Batten Cover Corners
Product Description

The Ultra-high Partition Wall can be up to 16 meters, and the ultra-high movable partition wall brings a lot of convenience to people's work. The raw material of the wood board can choose MDF, melamine board and flame retardant plywood as the board. Due to the large volume of the Ultra-High Partition Wall, in order to avoid the damage of the partition wall door panel during transportation, it is generally difficult to install the ultra-high movable partition wall by splicing it on site.



Specifications

Type 65 type, 80 type, 100 type, ultra high 100 type.
Finish melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel
Density  28~32kg/m²
STC 40db-50db
Dimensions width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg
Structure 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing


Product Structure


Banquet Hall Customization High Quality Movable Partition for Hall Movable Partitions for Hall
Banquet Hall Customization High Quality Movable Partition for Hall Movable Partitions for Hall



Panel Suspension  Top hunge system without the need for a floor track.
Panel Width Each panel 600mm-1200mm.
Track Aluminum OR Steel Track
Roller on panel Single or double  roller.
Panel Frames  Heavy-duty steel-gusseted aluminum inner frames reinforced with  full height.
Top&bottm seals Top and bottom pressure retractable seals ensure effortless moved and locked.
Module 700mm - 1200mm maximum.
Panel stacking Numerous panel stacking options for complete flexibility.
Panel face  MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard




Banquet Hall Customization High Quality Movable Partition for Hall Movable Partitions for Hall

Ultra high 100 type

    Soundproof Movable Walls is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high Soundproof Movable Walls can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.

Features

  • Load bearing of each meter is more than 2000 KGS
  • Each pulley bearing more than 1500 KGS
  • Easily moved even being pushed at waist-high
  • The panel can make a turn automatically as sliding in the straight rail


Banquet Hall Customization High Quality Movable Partition for Hall Movable Partitions for Hall

Banquet Hall Customization High Quality Movable Partition for Hall Movable Partitions for Hall

Stacking Ways

Banquet Hall Customization High Quality Movable Partition for Hall Movable Partitions for HallApplications

Banquet Hall Customization High Quality Movable Partition for Hall Movable Partitions for Hall
Banquet Hall Customization High Quality Movable Partition for Hall Movable Partitions for Hall
Banquet Hall Customization High Quality Movable Partition for Hall Movable Partitions for Hall
Banquet Hall Customization High Quality Movable Partition for Hall Movable Partitions for Hall


Banquet Hall Customization High Quality Movable Partition for Hall Movable Partitions for Hall

Design of Movable Wall Panels :

The Movable Wall Panels used in the hotel banquet hall can meet any requirements of different customers and design a unique style. Of course, the interior design can learn from domestic and foreign traditions and existing design achievements, but it cannot be just a simple "reference", regardless of the environment. It is also not advisable to "apply" to the type of building. Modern interior design should advocate innovation that combines the actual situation such as site size and style. For example, for the interior design of a hotel banquet hall, we can't just draw the scoop just like the gourd, but blindly use the broadness as the general model of design. Instead, we should pay attention to the actual use needs of the hotel and the hotel environment style and other factors for reasonable planning. The hotel banquet hall is relatively spacious, so it is necessary to have both the reception function of large-scale banquets and the use of diversified banquet halls. In the process of designing and installing the plan, we will combine the needs of customers and the style of the hotel banquet hall to innovate the design.

Using this kind of hotel with flexible personality and a sense of partition design, it can release a fixed fixed space in a large space, and make the expansion of the speech environment adapt to various needs of use. It is necessary to divide the large banquet hall into multiple banquet halls. Space, the need for some small boxes in the dining room of the small banquet hall; no need to separate the small space, put away the original event time of the large banquet hall again, and expand the application scope of the overall space, widely used and easy to lift, again with A convenient way to present a large banquet environment. With the effect of moving, this hotel wall is an effective way to make the space achieve "effective plagiarism".

We realize the partition wall activity in the form of the interior design, which is the focus of the innovative form of the hotel event space.

We use the movable partition wall to improve the inherent image of the hotel banquet hall, so when I design the movable partition wall plan, I need to add many novel and highly compatible factors to the hotel, so that we can transform the traditional role of the environment. Innovative and suitable for their own hotel banquet hall style event partition is an excellent partition wall, in order to play a real role. Be sure to choose high-quality partition materials to ensure their safety.


Product Categories : Ultra-high Partition Wall
