High Quality movable office partitions walls

$89.99 - 129.99 /Square Meter
Payment Type:
T/T
Incoterm:
FOB,CIF,EXW
Min. Order:
20 Square Meter
Transportation:
Ocean
Port:
SHENZHEN,GUANGZHOU
Share:
  • Product Description
Overview
Product Attributes

Model No.MQ-PARTITION

Warranty Service5 Years

After-sales ServiceOnline Technical Support, Return And Replacement, Other

Engineering Solution CapabilityTotal Solution For Projects

Application ScenarioHotel, Hall, Gym, Home Office

Design StyleContemporary, Scandinavian, Eclectic, Victorian, Traditional, Postmodern, Southwestern, Japanese, Modern, Mediterranean, Craftsman, Chinese, Minimalist, Coastal, Mid-Century Modern, French, Industrial, Rustic, Transitional

Place Of OriginChina

Model NO.Movable Partitions

TypeMelamine MDF Panel, Fireproof PVC Board, Fabric

ApplicationOffice, Hotel Banquet Hall, etc.

Main MaterialAluminum Frame and Track

Soundproof MaterRock Rool , Glass Wool

Soundproof Stc40dB-50dB

DimensionsW700-1200mm, H2000-5200mm, Thickness 80-110mm

Door Panel WeightMax 750kg/Panel

Stacking WayCentre Partiting; Side Parking

Supply Ability & Additional Information

PackagingCarton Paper Packaging, MDF Batten Cover Corners

Productivity5000sq/Month

TransportationOcean

Place of OriginChina

Supply Ability5000sq/Month

CertificateMagic Cube

HS Code76101000

PortSHENZHEN,GUANGZHOU

Payment TypeT/T

IncotermFOB,CIF,EXW

Packaging & Delivery
Selling Units:
Square Meter
Package Type:
Carton Paper Packaging, MDF Batten Cover Corners
Product Description

In addition to the use of mobile professional space, the Moveable Partition Wall of the hotel is a practical appearance change. Because its partition is flexible and free to move, its traditional movable partition partition space, the space is divided in this way, its installation cycle is very short, and the installation of large format partition boards can be completed, because the installation of Moveable Partition Wall also has a complete preset function. Set rules and simple system assembly method, no gas and polluting waste will be released after construction.


Specifications

Type 65 type, 80 type, 100 type, ultra high 100 type.
Finish melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel
Density  28~32kg/m²
STC 40db-50db
Dimensions width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg
Structure 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing


Product Structure


Banquet Hall Operable Wall System Vertical Foldable Partitions for Meeting Room or Hall
Banquet Hall Operable Wall System Vertical Foldable Partitions for Meeting Room or Hall



Panel Suspension  Top hunge system without the need for a floor track.
Panel Width Each panel 600mm-1200mm.
Track Aluminum OR Steel Track
Roller on panel Single or double  roller.
Panel Frames  Heavy-duty steel-gusseted aluminum inner frames reinforced with  full height.
Top&bottm seals Top and bottom pressure retractable seals ensure effortless moved and locked.
Module 700mm - 1200mm maximum.
Panel stacking Numerous panel stacking options for complete flexibility.
Panel face  MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard




Banquet Hall Operable Wall System Vertical Foldable Partitions for Meeting Room or Hall

Ultra high 100 type

    Ultra-high Moveable Wall is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type Moveable Wall is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high partition can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.

Features

  • Load bearing of each meter is more than 2000 KGS
  • Each pulley bearing more than 1500 KGS
  • Easily moved even being pushed at waist-high
  • The panel can make a turn automatically as sliding in the straight rail


Banquet Hall Operable Wall System Vertical Foldable Partitions for Meeting Room or Hall

Banquet Hall Operable Wall System Vertical Foldable Partitions for Meeting Room or Hall

Stacking Ways

Banquet Hall Operable Wall System Vertical Foldable Partitions for Meeting Room or HallApplications

Banquet Hall Operable Wall System Vertical Foldable Partitions for Meeting Room or Hall
Banquet Hall Operable Wall System Vertical Foldable Partitions for Meeting Room or Hall
Banquet Hall Operable Wall System Vertical Foldable Partitions for Meeting Room or Hall
Banquet Hall Operable Wall System Vertical Foldable Partitions for Meeting Room or Hall


Banquet Hall Operable Wall System Vertical Foldable Partitions for Meeting Room or Hall

Partition refers to the façade that is specially used to separate indoor space, and the application is more flexible, such as partition wall, partition, movable display board, movable screen, mobile partition, mobile screen, mobile Sound Insulation wall, etc., originating from Japanese technology. The movable partition has the characteristics of easy installation, reusability, industrial production, fire prevention and environmental protection.

What are the benefits of moving partition walls?

The Movable Partition Wall is widely loved because of its strong mobility and convenient storage. Its function is the same as that of the traditional fixed wall. It can divide a large space into multiple small spaces or combine multiple small spaces into one large space. This movable partition wall is one of the best decorative ones. It is beautiful and has strong sound insulation effect. It is often used in hotel lobbies, conference halls and other places.

Active partitions can also be called movable partition doors, high-quality mobile walls, mobile partition doors, and track partition doors. All represent movable partition walls.

The Movable Partition Wall has many advantages. For example, there is no need to install the track on the floor, but it is enough to install the track on the ceiling. The design of the partition track on the top will be more conducive to the push-pull partition, and it will not make the floor look particularly complicated, and no need Clean up anytime. Another example is the movable partition wall, which is very stable once partitioned, not easy to shake, and has high safety, so it can be used with confidence.

The movable partition wall has the characteristics of sound insulation, heat insulation and fire prevention, and has a high sound insulation coefficient. Separating into small spaces can also save the power consumption of air conditioners, achieve energy-saving effects, and have good energy-saving and low-cost effects.

In addition to these practical features, the movable partition wall has various styles that are very beautiful and generous, and you can choose the appropriate style according to the interior decoration style. It is easy to install and easy to put away. If you want to put it away, you can hide it in a special storage cabinet, which will not affect the overall beauty of the building interior.

When movable partitions are used in hotel restaurants

When decorating, pay attention to reflecting the mood of life. According to the introduction of the movable partition manufacturer, the furniture mainly involved in the early hotel design is the dining table, chairs, curtains, etc. During decoration and decoration, some items should be placed on the dining table, or some practical ornaments will increase the interest of life, such as Set out some fine ceramic tableware, beautiful glassware, etc.
