Wooden movable acoustic wall partition system

$89.99 - 129.99 /Square Meter
Sound-absorbing board varieties:
Share:
  • Product Description
Overview
Product Attributes

BrandMAGIC CUBE

Main ApplicationCommercial Furniture

Types OfOffice Furniture

Whether To Support Mail Order Packaging (special Packaging For Cross-border E-commerce)Y

Supply Ability & Additional Information

TransportationOcean

Place of OriginCHINA

CertificateCE

HS Code 76101000

Payment TypeT/T

IncotermFOB,EXW,CIF

Packaging & Delivery
Selling Units:
Square Meter

Specifications

Type 65 type, 80 type, 100 type, ultra high 100 type.
Finish melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel
Density  28~32kg/m²
STC 40db-50db
Dimensions width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg
Structure 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing


Product Structure


Wholesale High Strength Cheap Unique Movable Wooden Partition Design Movable Sound Panels
Wholesale High Strength Cheap Unique Movable Wooden Partition Design Movable Sound Panels



Panel Suspension  Top hunge system without the need for a floor track.
Panel Width Each panel 600mm-1200mm.
Track Aluminum OR Steel Track
Roller on panel Single or double  roller.
Panel Frames  Heavy-duty steel-gusseted aluminum inner frames reinforced with  full height.
Top&bottm seals Top and bottom pressure retractable seals ensure effortless moved and locked.
Module 700mm - 1200mm maximum.
Panel stacking Numerous panel stacking options for complete flexibility.
Panel face  MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard




Wholesale High Strength Cheap Unique Movable Wooden Partition Design Movable Sound Panels

Ultra high 100 type

    Ultra-high Movable Partition is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high partition can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.

Features

  • Load bearing of each meter is more than 2000 KGS
  • Each pulley bearing more than 1500 KGS
  • Easily moved even being pushed at waist-high
  • The panel can make a turn automatically as sliding in the straight rail


Wholesale High Strength Cheap Unique Movable Wooden Partition Design Movable Sound Panels

Wholesale High Strength Cheap Unique Movable Wooden Partition Design Movable Sound Panels

Stacking Ways

Wholesale High Strength Cheap Unique Movable Wooden Partition Design Movable Sound PanelsApplications

Wholesale High Strength Cheap Unique Movable Wooden Partition Design Movable Sound Panels
Wholesale High Strength Cheap Unique Movable Wooden Partition Design Movable Sound Panels
Wholesale High Strength Cheap Unique Movable Wooden Partition Design Movable Sound Panels
Wholesale High Strength Cheap Unique Movable Wooden Partition Design Movable Sound Panels


Wholesale High Strength Cheap Unique Movable Wooden Partition Design Movable Sound Panels

The ultra-high type demountable partition wall can be called a high partition or a moveable acoustic walls. Different from the ordinary partition wall, it is a partition whose height is as high as the ceiling and can divide the space at the same time. Professional type high partition door panels have general The function of the wall, separating the space, is much more prominent than the traditional partition wall in terms of lighting, Sound Insulation, fire prevention, environmental protection, easy installation, reusability and mass production.



The track of the demountable partition wall is installed on the ceiling, there is no track on the ground, no ground track is suspended, but it is more stable and reliable. The moveable acoustic walls is generally made of PAR sound-absorbing glass fiber sound insulation cotton, and the partition wall door panel is surrounded by an all-inclusive aluminum frame, the board is made of melamine board, and the board is sandwiched with sound insulation cotton. Melamine board has relatively good fire performance, and this board is available in a variety of colors and styles. Through proper craftsmanship, the entire wall can be flexibly and conveniently retracted through the track. Check. When accepting acoustic movable partition wall, first check whether the rails of the movable partitions are firmly connected and whether the positions are closely overlapped; whether they can feel safe, stable, and sensitive when pushing and pulling, and push and pull several times, as long as any inappropriate jam occurs. It should be pointed out to communicate effectively with the installer to solve the problem, observe whether the wall is smooth and smooth, and use the touched wall to experience the hand feel. If there is a sticky or uneven place, manual grinding and optimization should be required; and the last point is to ensure the activity The acoustic movable partition wall remains noise-free when pushed and pulled.
