Model No.: MQ-PARTITION
Brand: MAGIC CUBE
Warranty Service: 5 Years
After-sales Service: Online Technical Support, Return And Replacement
Engineering Solution Capability: Total Solution For Projects, Others
Application Scenario: Hotel, Workshop, Gym, Home Bar, Home Office, Office Building, Hall
Design Style: Contemporary, Farmhouse, Rustic, Mid-Century Modern, Chinese, Traditional, Scandinavian, European, French, Modern, Postmodern, Asian, Transitional, Minimalist, Eclectic, Tropical, Mediterranean, Southwestern, Victorian, Industrial, Coastal, Craftsman, Japanese, Midcentury
Place Of Origin: China
Model NO.: Movable Partitions
Type: Melamine MDF Panel, Fireproof PVC Board, Fabric
Application: Office, Hotel Banquet Hall, etc.
Main Material: Aluminum Frame and Track
Width: 750mm~2000mm
Soundproof Stc: 40dB-50dB
Dimensions: W700-1200mm, H2000-5200mm, Thickness 80-110mm
Open Way: Sliding Partition
Stacking Way: Centre Partiting; Side Parking
Specification: 65, 85, 100, 125
Packaging: Carton Paper Packaging, MDF Batten Cover Corners
Productivity: 5000sq/Month
Transportation: Ocean
Place of Origin: CHINA
Supply Ability: 5000sq/Month
Certificate: CE
HS Code: 76101000
Port: SHENZHEN,GUANGZHOU
Payment Type: T/T
Incoterm: FOB,CIF,EXW
The Movable Partition Wall used in each place is completely different. The partition wall ordered in this place can only be used in this place, because the precise size data of the site size needs to be recorded before the movable partition wall panel is made, and you can choose by yourself. Plates, finishes and colours. There are four types of our movable partition walls, 65 type, 80 type, 100 type and super high 100 type. Different types of Movable Partition Wall are selected according to different places, and the thickness is customized according to the height and customer needs.
Type | 65 type, 80 type, 100 type, ultra high 100 type. |
Finish | melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel |
Density | 28~32kg/m² |
STC | 40db-50db |
Dimensions | width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg |
Structure | 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing |
Panel Suspension | Top hunge system without the need for a floor track. |
Panel Width | Each panel 600mm-1200mm. |
Track | Aluminum OR Steel Track |
Roller on panel | Single or double roller. |
Panel Frames | Heavy-duty steel-gusseted aluminum inner frames reinforced with full height. |
Top&bottm seals | Top and bottom pressure retractable seals ensure effortless moved and locked. |
Module | 700mm - 1200mm maximum. |
Panel stacking | Numerous panel stacking options for complete flexibility. |
Panel face | MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc. |
Finishes | Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard |
Ultra high 100 type
Moveable Wall is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Movable Wall ,Moveable Wall is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high Moveable Wall can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.
Features
Stacking Ways
Applications
Features:
1. The height of the partition door is sometimes as high as 15 meters. When people push the partition door, the height that can be reached by the human hand is limited. Even such a high partition wall door can use the movable partition wall smoothly by relying on the strength of one person.
2. The material of the Movable Wall ,Moveable Wall door panel is smooth and not thorny, and it is easy to clean and wipe off the stains. Use a rag or a foldable long mop to simply wet the surface with clean water to wipe the dust and dirt on the surface. It is easy to wipe off with a light wipe.
3. The Ultra-high Partition Wall can not only prevent fire and heat insulation, but also has a Sound Insulation coefficient of up to 50dB, which means that it can isolate the voice of ordinary people. Someone is talking in a meeting next door. Automatically becomes smaller or even disappears inaudible.
4. Our Movable Wall ,Moveable Wall door panels do not have wheels, and are driven entirely by the rails above the ceiling. This way no marks will be left on the floor.
5. In order to better meet the customization requirements of each customer, our door has experienced professional designers to design construction plans for customers, combining the colors and styles selected by customers and the data that have been measured on the customer site and the needs of customers. Integrate and summarize ZAAI to design a construction plan that satisfies the customer.
Product Categories : Movable Wall
