HomeProductsMovable WallFabric decorative room divider board
Fabric decorative room divider board
  • Fabric decorative room divider board
  • Fabric decorative room divider board
  • Fabric decorative room divider board
  • Fabric decorative room divider board
  • Fabric decorative room divider board
  • Fabric decorative room divider board

Fabric decorative room divider board

$89.99 - 129.99 /Square Meter
Payment Type:
T/T
Incoterm:
FOB,CIF,EXW
Min. Order:
20 Square Meter
Transportation:
Ocean
Port:
SHENZHEN,GUANGZHOU
Share:
  • Product Description
< >
Overview
Product Attributes

Model No.: MQ-PARTITION WALL

Brand: MAGIC CUBE

Warranty Service: 5 Years

After-sales Service: Online Technical Support, Return And Replacement

Engineering Solution Capability: Total Solution For Projects

Application Scenario: Hotel, Villa

Design Style: Contemporary, Farmhouse, Rustic, Mid-Century Modern, Chinese, Traditional, European, French, Scandinavian

Place Of Origin: China

Model NO.: Movable Partitions

Type: Melamine MDF Panel, Fireproof PVC B

Application: Office, Hotel Banquet Hall, etc.

Main Material: Aluminum Frame and Track

Soundproof Mater: Rock Rool , Glass Wool

Supply Ability & Additional Information

Packaging: Carton Paper Packaging, MDF Batten Cover Corners

Productivity: 5000sq/Month

Transportation: Ocean

Place of Origin: CHINA

Supply Ability: 5000sq/Month

Certificate: CE

HS Code: 76101000

Port: SHENZHEN,GUANGZHOU

Payment Type: T/T

Incoterm: FOB,CIF,EXW

Packaging & Delivery
Selling Units:
Square Meter
Package Type:
Carton Paper Packaging, MDF Batten Cover Corners
Product Description

The installation process of the Movable Partition Wall:

1. Positioning measurement. When installing, professionals will measure according to the indoor floor plan, release the control line, and then guide the position line to the roof, and then finalize the internal marking and construction details.

2. Installation of steel structure and fixed parts. The steel structure is a load-bearing member linking the ceiling and the track, it is very important, and even involves the safety of the entire Movable Partition Wall. In this step, it is necessary to weld the fixed parts to death according to the requirements of the construction drawing, and at the same time carry out anti-rust treatment on all the metal parts.

Install the track. The fixing method of the suspended track is to install a pulley on the top surface of the partition wall door panel and connect it with the upper suspended track. The track of the light movable partition wall is fixed on the top plank or the steel frame with wood screws or counterscrew. The heavy-duty movable partition wall is fixed on the steel frame by screw or world welding.




Specifications

Type 65 type, 80 type, 100 type, ultra high 100 type.
Finish melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel
Density  28~32kg/m²
STC 40db-50db
Dimensions width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg
Structure 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing



Product Structure


High Quality Movable Divider on Wheels Movable Partition for Hall Stylish Drop Ceiling Panels
High Quality Movable Divider on Wheels Movable Partition for Hall Stylish Drop Ceiling Panels



Panel Suspension  Top hunge system without the need for a floor track.
Panel Width Each panel 600mm-1200mm.
Track Aluminum OR Steel Track
Roller on panel Single or double  roller.
Panel Frames  Heavy-duty steel-gusseted aluminum inner frames reinforced with  full height.
Top&bottm seals Top and bottom pressure retractable seals ensure effortless moved and locked.
Module 700mm - 1200mm maximum.
Panel stacking Numerous panel stacking options for complete flexibility.
Panel face  MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard




High Quality Movable Divider on Wheels Movable Partition for Hall Stylish Drop Ceiling Panels

Ultra high 100 type

    Ultra-high Moveable Wall is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high partition can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.

Features

  • Load bearing of each meter is more than 2000 KGS
  • Each pulley bearing more than 1500 KGS
  • Easily moved even being pushed at waist-high
  • The panel can make a turn automatically as sliding in the straight rail


High Quality Movable Divider on Wheels Movable Partition for Hall Stylish Drop Ceiling Panels

High Quality Movable Divider on Wheels Movable Partition for Hall Stylish Drop Ceiling Panels

Stacking Ways

High Quality Movable Divider on Wheels Movable Partition for Hall Stylish Drop Ceiling PanelsApplications

High Quality Movable Divider on Wheels Movable Partition for Hall Stylish Drop Ceiling Panels
High Quality Movable Divider on Wheels Movable Partition for Hall Stylish Drop Ceiling Panels
High Quality Movable Divider on Wheels Movable Partition for Hall Stylish Drop Ceiling Panels
High Quality Movable Divider on Wheels Movable Partition for Hall Stylish Drop Ceiling Panels


High Quality Movable Divider on Wheels Movable Partition for Hall Stylish Drop Ceiling Panels

What are the characteristics of Moveable Partition Wall?

The Moveable Partition Wall is a Movable Wall that can divide a large space into a small space or connect a small space into a large space anytime and anywhere according to the needs and has the function of a general wall.

It has the following features:

1. There is no track on the floor, no floor rail suspension, only need to install the track on the ceiling during installation

2. The partition is stable and safe, stable and reliable after correct installation, not easy to swing

3. The Sound Insulation effect is good, the partition material is made of environmentally friendly materials, and the sound insulation coefficient can reach 50dB

4. Excellent thermal insulation performance, eliminates different occupancy rates, and divides large spaces into small spaces, which can reduce the power consumption of air conditioners

5. High-efficiency fire prevention, which is made of high-efficiency and high-quality fire-resistant materials, with excellent fire-proof performance

6. The appearance is simple and elegant, the surface can be decorated arbitrarily, or it can be unified with the interior decoration effect

7. It is convenient to retract and retract, the partition can be retracted and retracted freely, and the promotion is more flexible. One person can complete the entire process of retracting and partitioning.

8. It is convenient to store. When closing the board, the partition is hidden in a special storage cabinet, which will not affect the aesthetics of the overall space at all.

9. There are many applications for partitions, such as: conference halls, exhibition halls, restaurants, high-clean factories and offices, etc.

How to design the movable partition wall?

Design principle of movable partition wall: movable partition wall is a non-load-bearing wall, so its shape is highly variable and has a high degree of freedom. It can change any shape without being restricted, so it is more suitable for any space transformation. When designing a space, we Special attention should be paid to the combination of partition and space, as well as the uniformity of height and length. Only when the consistency becomes stronger can it be enough to create an ideal movable partition wall. Otherwise only you make a Poor spatial effect at last.
