High quality for highway acoustic sound divider

$89.99 - 129.99 /Square Meter
Sound-absorbing board varieties:
Share:
  • Product Description
Overview
Product Attributes

Model No.MQ-PARTITION

BrandMAGIC CUBE

Warranty Service5 Years

After-sales ServiceOnline Technical Support, Return And Replacement

Engineering Solution CapabilityTotal Solution For Projects

Application ScenarioHall, Gym, Hotel, Workshop

Design StyleContemporary, Farmhouse, Rustic, Mid-Century Modern, Chinese, Traditional, Scandinavian, European, French, Asian, Transitional, Modern, Postmodern, Eclectic, Tropical, Minimalist, Mediterranean, Southwestern, Victorian, Industrial, Coastal, Craftsman, Japanese, Midcentury

Place Of OriginChina

Model NO.Movable Partitions

TypeMelamine MDF Panel, Fireproof PVC Board, Fabric

ApplicationOffice, Hotel Banquet Hall, etc.

Main MaterialAluminum Frame and Track

Soundproof MaterRock Rool , Glass Wool

Soundproof Stc40dB-50dB

DimensionsW700-1200mm, H2000-5200mm, Thickness 80-110mm

Stacking WayCentre Partiting; Side Parking

Open WaySliding Partition

Supply Ability & Additional Information

PackagingCarton Paper Packaging, MDF Batten Cover Corners

Productivity5000sq/Month

TransportationOcean

Place of OriginCHINA

Supply Ability5000sq/Month

CertificateCE

HS Code76101000

PortSHENZHEN,GUANGZHOU

Payment TypeT/T

IncotermFOB,CIF,EXW

Packaging & Delivery
Selling Units:
Square Meter
Package Type:
Carton Paper Packaging, MDF Batten Cover Corners
Product Description

In addition to the use of mobile professional space, the Movable Partition Wall of the hotel is a practical appearance change. Because its partition is flexible and free to move, its traditional movable partition partition space, the space is divided in this way, its installation cycle is very short, and the installation of large format partition boards can be completed, because the installation of Movable Partition Wall also has a complete preset function. Set rules and simple system assembly method, no gas and polluting waste will be released after construction.


Specifications

Type 65 type, 80 type, 100 type, ultra high 100 type.
Finish melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel
Density  28~32kg/m²
STC 40db-50db
Dimensions width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg
Structure 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing



Product Structure


Eco Friendly Acoustic Wall Panels Timber Ceiling Soundproof Foldable Divider for Hall or Cinema
Eco Friendly Acoustic Wall Panels Timber Ceiling Soundproof Foldable Divider for Hall or Cinema



Panel Suspension  Top hunge system without the need for a floor track.
Panel Width Each panel 600mm-1200mm.
Track Aluminum OR Steel Track
Roller on panel Single or double  roller.
Panel Frames  Heavy-duty steel-gusseted aluminum inner frames reinforced with  full height.
Top&bottm seals Top and bottom pressure retractable seals ensure effortless moved and locked.
Module 700mm - 1200mm maximum.
Panel stacking Numerous panel stacking options for complete flexibility.
Panel face  MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard




Eco Friendly Acoustic Wall Panels Timber Ceiling Soundproof Foldable Divider for Hall or Cinema

Ultra high 100 type

    Ultra-high Moveable Wall is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high Moveable Wall can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.

Features

  • Load bearing of each meter is more than 2000 KGS
  • Each pulley bearing more than 1500 KGS
  • Easily moved even being pushed at waist-high
  • The panel can make a turn automatically as sliding in the straight rail


Eco Friendly Acoustic Wall Panels Timber Ceiling Soundproof Foldable Divider for Hall or Cinema

Eco Friendly Acoustic Wall Panels Timber Ceiling Soundproof Foldable Divider for Hall or Cinema

Stacking Ways

Eco Friendly Acoustic Wall Panels Timber Ceiling Soundproof Foldable Divider for Hall or CinemaApplications

Eco Friendly Acoustic Wall Panels Timber Ceiling Soundproof Foldable Divider for Hall or Cinema
Eco Friendly Acoustic Wall Panels Timber Ceiling Soundproof Foldable Divider for Hall or Cinema
Eco Friendly Acoustic Wall Panels Timber Ceiling Soundproof Foldable Divider for Hall or Cinema
Eco Friendly Acoustic Wall Panels Timber Ceiling Soundproof Foldable Divider for Hall or Cinema


Eco Friendly Acoustic Wall Panels Timber Ceiling Soundproof Foldable Divider for Hall or Cinema

Partitions are often used in hotels because the hotel banquet halls, hotel conference rooms and restaurants in the hotel lobby are flexible and easy to operate in order to create multiple independent small spaces. favorite. Take the hotel conference room as an example. The hotel conference room needs to meet the needs of enterprises from all walks of life. The number of people in the conference room is as small as 20 or 30, and the maximum number is hundreds. The number of people is very different, and it is difficult to carry out work smoothly. The emergence of ultra-high Moveable Partition Wall solves this problem, so that we can use the space of the conference room more efficiently.

The reason why the hotel conference room can create the space required by various groups of people, the movable partition wall has the outstanding characteristics compared with other partition walls:



1. Compared with the physical Moveable Partition Wall, the mobile partition wall can be pushed and pulled to expand or store, dividing the overall space into a variety of small spaces, even in large conference rooms. In this way, there is no need to waste time and energy to rationally arrange the space. Only one space can be divided into multiple small spaces, and the tables and chairs used for the meeting can be arranged to meet the needs of different passenger flows.

2. A good conference room must have Sound Insulation. Meeting rooms are needed for decision-making in life and society, so its privacy should be very good. The sound insulation coefficient of the movable partition wall is very high, which can isolate 50dB of noise at most, filtering outdoor noise and blocking external sounds. The intervention will not affect the efficiency of the meeting in the conference room. It can not only protect the privacy of the meeting but also ensure the quiet environment.



3. The Moveable Partition Wall is not troublesome at all. It relies on rails for push-pull movement, and it is effortless for a person to manually move the partition wall. The movable partition wall has a good thermal insulation and fireproof function because the upper and lower battens should be opened after the partition is unfolded, so that the partition wall can firmly withstand the ceiling and the ground.
