High quality acoustic sound divider

$89.99 - 129.99 /Square Meter
Sound-absorbing board varieties:
Share:
  • Product Description
Overview
Product Attributes

Model No.MQ-PARTITION

BrandMAGIC CUBE

Warranty Service5 Years

After-sales ServiceOnline Technical Support, Return And Replacement, Other

Engineering Solution CapabilityTotal Solution For Projects, Others

Application ScenarioHotel, Hall, Gym, Home Bar, Office Building, Home Office, Workshop

Design StyleContemporary, Scandinavian, Eclectic, Victorian, Traditional, Postmodern, Southwestern, Japanese, Modern, Mediterranean, Craftsman, Chinese, Minimalist, Coastal, Mid-Century Modern, French, Industrial, Rustic, Transitional, Midcentury, European, Farmhouse, Asian, Tropical

Place Of OriginChina

Model NO.Movable Partitions

TypeMelamine MDF Panel, Fireproof PVC Board, Fabric

ApplicationOffice, Hotel Banquet Hall, etc.

Thickness65mm, 85mm, 100mm or 125mm

Height3500mm~16000mm

Width750mm~2000mm

Sound Insulation (dB)35-50dB

Fire Rating1.5 Hours

Door Panel WeightMax 750kg/Panel

Motor PowerAC150V~250V

Supply Ability & Additional Information

PackagingCarton Paper Packaging, MDF Batten Cover Corners

ProductivityCHINA

TransportationOcean

Place of OriginCHINA

Supply Ability5000sq/Month

CertificateCE

HS Code76101000

PortSHENZHEN

Payment TypeT/T,Others

IncotermFOB,CIF,EXW

Packaging & Delivery
Selling Units:
Square Meter
Package Type:
Carton Paper Packaging, MDF Batten Cover Corners
Product Description

The ultra-high Moveable Wall can be up to 16 meters, and the ultra-high movable partition wall brings a lot of convenience to people's work.

Moveable Wall are generally used in public workplaces such as banquet halls and exhibitions. It must be possible to create an excellent customer's activity space at the same time according to the actual situation, so that there are many business-friendly functions that can be next door.



Specifications

Type 65 type, 80 type, 100 type, ultra high 100 type.
Finish melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel
Density  28~32kg/m²
STC 40db-50db
Dimensions width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg
Structure 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing


Product Structure


Wholesale High Strength Cheap Unique Soundproof Movable Panels for Classroom and Library
Wholesale High Strength Cheap Unique Soundproof Movable Panels for Classroom and Library



Panel Suspension  Top hunge system without the need for a floor track.
Panel Width Each panel 600mm-1200mm.
Track Aluminum OR Steel Track
Roller on panel Single or double  roller.
Panel Frames  Heavy-duty steel-gusseted aluminum inner frames reinforced with  full height.
Top&bottm seals Top and bottom pressure retractable seals ensure effortless moved and locked.
Module 700mm - 1200mm maximum.
Panel stacking Numerous panel stacking options for complete flexibility.
Panel face  MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard




Wholesale High Strength Cheap Unique Soundproof Movable Panels for Classroom and Library

Ultra high 100 type

    Ultra-high Moveable Wall is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters Moveable Wall can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.

Features

  • Load bearing of each meter is more than 2000 KGS
  • Each pulley bearing more than 1500 KGS
  • Easily moved even being pushed at waist-high
  • The panel can make a turn automatically as sliding in the straight rail


Wholesale High Strength Cheap Unique Soundproof Movable Panels for Classroom and Library

Wholesale High Strength Cheap Unique Soundproof Movable Panels for Classroom and Library

Stacking Ways

Wholesale High Strength Cheap Unique Soundproof Movable Panels for Classroom and LibraryApplications

Wholesale High Strength Cheap Unique Soundproof Movable Panels for Classroom and Library
Wholesale High Strength Cheap Unique Soundproof Movable Panels for Classroom and Library
Wholesale High Strength Cheap Unique Soundproof Movable Panels for Classroom and Library
Wholesale High Strength Cheap Unique Soundproof Movable Panels for Classroom and Library


Wholesale High Strength Cheap Unique Soundproof Movable Panels for Classroom and Library

To create a high-end atmosphere of the banquet hall, the space must be open, but under the condition of limited economic budget, it is impossible to establish its open space, because it is impossible for most hotels to spend a lot of money on low utilization rates. in the banquet hall. In order to make better use of limited space resources, active partitions solve these problems to a large extent.

Let's take a look at the characteristics of Movable Wall ,Moveable Wall

Although the Movable Wall ,Moveable Wall  is called "wall", it has the function of a general wall, but it is different from an ordinary wall. On the surface, the entire partition fan surface looks like a wall. In fact, it is composed of various components. The outer frame is made of aluminum alloy, which has strong stability and is not easy to be corroded. More usage requirements, support customer customization. In order to meet different usage requirements, it can be replaced with alloy materials that meet the properties to ensure a certain special purpose, and customized upgrades are recommended for a small number of environments with higher specifications.

Next, we will introduce the part of the fan surface. The "wall" body is made of various materials such as sound-absorbing cotton, so that it has the functions of Sound Insulation, heat insulation and energy saving. Communication of relevant performance, improve the sound insulation performance of the partition fan. The customizability of the fan surface is also one of the remarkable characteristics of the Moveable Wall. The surface can be decorated with various materials such as "soft package", "hard package" and "wood veneer" to enhance the visual perception and integrate it into the environment. , to promote elegant, high-end or classic interior space.
