Banquet Hall moveable wall systems



Product Details

Product Structure






Panel Suspension	Top hunge system without the need for a floor track.
Panel Width	Each panel 600mm-1200mm.
Track	Aluminum OR Steel Track
Roller on panel	Single or double  roller.
Panel Frames	Heavy-duty steel-gusseted aluminum inner frames reinforced with  full height.
Top&bottm seals	Top and bottom pressure retractable seals ensure effortless moved and locked.
Module	700mm - 1200mm maximum.
Panel stacking	Numerous panel stacking options for complete flexibility.
Panel face	MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes	Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard



Ultra high 100 type

    Ultra-high Movable Partition is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high partition can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.

Features

• Load bearing of each meter is more than 2000 KGS
• Each pulley bearing more than 1500 KGS
• Easily moved even being pushed at waist-high
• The panel can make a turn automatically as sliding in the straight rail

Stacking Ways

Applications

What are the benefits of moveable soundproof walls?

The movable soundproof walls wall is widely loved because of its strong mobility and convenient storage. Its function is the same as that of the traditional fixed wall. It can divide a large space into multiple small spaces or combine multiple small spaces into one large space. This movable partition wall is one of the best decorative ones. It is beautiful and has strong sound insulation effect. It is often used in hotel lobbies, conference halls and other places.

Movable walls commercial can also be called movable partition doors, high-quality mobile walls, mobile partition doors, and track partition doors. All represent movable partition walls.

The movable partition wall has many advantages. For example, there is no need to install the track on the floor, but it is enough to install the track on the ceiling. The design of the movable walls commercial track on the top will be more conducive to the push-pull partition, and it will not make the floor look particularly complicated, and no need Clean up anytime. Another example is the movable partition wall, which is very stable once partitioned, not easy to shake, and has high safety, so it can be used with confidence.

The movable soundproof walls has the characteristics of sound insulation, heat insulation and fire prevention, and has a high sound insulation coefficient. Separating into small spaces can also save the power consumption of air conditioners, achieve energy-saving effects, and have good energy-saving and low-cost effects.
