Office interior design office soundproof partition wall

$89.99 - 129.99 /Square Meter
Sound-absorbing board varieties:
Share:
  • Product Description
Overview
Product Attributes

Model No.MQ-PARTITION

BrandMAGIC CUBE

Main ApplicationCommercial Furniture

Types OfOffice Furniture

Whether To Support Mail Order Packaging (special Packaging For Cross-border E-commerce)Y

Supply Ability & Additional Information

PackagingCarton Paper Packaging, MDF Batten Cover Corners

Productivity5000sq/Month

TransportationOcean

Place of OriginChina

Supply Ability5000sq/Month

CertificateCE

HS Code76101000

Payment TypeT/T

IncotermFOB,CIF,EXW

Packaging & Delivery
Selling Units:
Square Meter
Package Type:
Carton Paper Packaging, MDF Batten Cover Corners
Product Description

    moveable partitions wall is a Movable Wall with general wall functions that can divide large space into small space or connect small space into large space at any time according to needs. It can play a role of multiple functions in one hall or one room. The moveable partitions wall brings great convenience to people's work. For example, you can fold it on one side when you need it, so that the two spaces are temporarily joined to make them appear larger, which is convenient for temporary departmental meetings.

Specifications

Type 65 type, 80 type, 100 type, ultra high 100 type.
Finish melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel
Density  28~32kg/m²
STC 40db-50db
Dimensions width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg
Structure 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing


Product Structure


Acoustic Folding Wooden Electrically Operated Removable Wall Room Divider Style Movable Partitions
Acoustic Folding Wooden Electrically Operated Removable Wall Room Divider Style Movable Partitions



Panel Suspension  Top hunge system without the need for a floor track.
Panel Width Each panel 600mm-1200mm.
Track Aluminum OR Steel Track
Roller on panel Single or double  roller.
Panel Frames  Heavy-duty steel-gusseted aluminum inner frames reinforced with  full height.
Top&bottm seals Top and bottom pressure retractable seals ensure effortless moved and locked.
Module 700mm - 1200mm maximum.
Panel stacking Numerous panel stacking options for complete flexibility.
Panel face  MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard




Acoustic Folding Wooden Electrically Operated Removable Wall Room Divider Style Movable Partitions

Ultra high 100 type

    Ultra-high acoustic moving walls is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high acoustic moving walls can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.

Features

  • Load bearing of each meter is more than 2000 KGS
  • Each pulley bearing more than 1500 KGS
  • Easily moved even being pushed at waist-high
  • The panel can make a turn automatically as sliding in the straight rail


Acoustic Folding Wooden Electrically Operated Removable Wall Room Divider Style Movable Partitions

Acoustic Folding Wooden Electrically Operated Removable Wall Room Divider Style Movable Partitions

Stacking Ways

Acoustic Folding Wooden Electrically Operated Removable Wall Room Divider Style Movable PartitionsApplications

Acoustic Folding Wooden Electrically Operated Removable Wall Room Divider Style Movable Partitions
Acoustic Folding Wooden Electrically Operated Removable Wall Room Divider Style Movable Partitions
Acoustic Folding Wooden Electrically Operated Removable Wall Room Divider Style Movable Partitions
Acoustic Folding Wooden Electrically Operated Removable Wall Room Divider Style Movable Partitions


Acoustic Folding Wooden Electrically Operated Removable Wall Room Divider Style Movable Partitions

The

Automatic Operable Walls is an existence that optimizes the space of the banquet hall. The unique charm of the partition is to make the monotonous banquet hall lobby more simple and elegant, to meet the needs of customers in multiple directions, and to design and install the plan according to the style and characteristics of the venue.



The characteristics of the hotel activity partition are as follows:

Sound Insulation

Our  Automatic Operable Walls have been tested and certified by authoritative institutions, and we can design and customize them according to the requirements of different customers. Of course, it is necessary to ensure that the sound insulation of movable partitions must be maintained to a high level.

safety

Our movable partition walls are all made of aluminum alloy frames and steel parts with inner cores, which are not easy to deform. With the skilled assembly process, the stability and safety of the movable partition walls are maximized.

flexibility

With the ultra-high-strength aluminum alloy track, the partition wall door can be pushed easily and conveniently, without noise, and can be retracted and placed freely, so as to adapt to various flexible and changeable space trends. It is easy and convenient to unfold and store the movable partition wall by the strength of only one person.



tightness

Multiple sealing strips are installed on the partition wall, so that the partition wall can effectively increase the sealing performance of the whole wall. The nodes use memory glue to maintain this characteristic and increase the sound insulation performance.





We focus on developing a variety of partition products, and are specialized in the development, production and installation of movable partitions. We have a modern factory, a large-scale customized partition production base, with exquisite production technology and strong strength. And provide pre-sale, sale, after-sale integration of a full range of services. We have introduced foreign advanced technology and strictly abide by international standards to produce high-quality hotel activity partitions. Strict selection of production materials, mechanized cutting, rich experience in splicing production for many years, high quality and stable. The biggest advantage of our products is good quality and high stability, long life, very easy to install.



Design and customization of hotel movable partition walls

1. According to different customer needs, it is necessary to carry out one-to-one tailor-made, so as to keep improving.

2. We have a domestic professional design team, which can design and formulate a more suitable installation plan for movable partitions according to the customer's requirements and careful investigation of the customer's site.

3. With years of senior experience in the industry, our construction team conducts standardized installations to ensure that each project can be completed on time.

4. We specialize in providing high-quality and thoughtful services for foreign star-rated hotels, government and enterprise units, conference rooms and other building spaces. The market has a high praise rate and will continue to improve.
