Model No.: MQ-PARTITION
Brand: MAGIC CUBE
Warranty Service: 5 Years
After-sales Service: Online Technical Support, Return And Replacement
Engineering Solution Capability: Total Solution For Projects
Application Scenario: Hotel, Villa, Hall, Gym, Mall, Office Building, Home Office, Home Bar
Design Style: Contemporary, Scandinavian, Eclectic, Victorian, Traditional
Place Of Origin: China
Model NO.: Movable Partitions
Type: Melamine MDF Panel, Fireproof PVC Board, Fabric
Application: Office, Hotel Banquet Hall, etc.
Main Material: Aluminum Frame and Track
Soundproof Mater: Rock Rool , Glass Wool
Soundproof Stc: 40dB-50dB
Dimensions: W700-1200mm, H2000-5200mm, Thickness 80-110mm
Stacking Way: Centre Partiting; Side Parking
Open Way: Sliding Partition
Packaging: Carton Paper Packaging, MDF Batten Cover Corners
Productivity: 5000sq/Month
Transportation: Ocean
Place of Origin: CHINA
Supply Ability: 5000sq/Month
Certificate: CE
HS Code: 76101000
Port: GUANGZHOU,SHENZHEN
Payment Type: T/T
Incoterm: FOB,CIF,EXW
A good hotel will also have a good movable partition wall, the Moveable Wall is very important, and the partition installation system next door is required for partition installation, which is convenient and accurate. The method is simple, the environment after installation is clean, and there is no remaining garbage.
The ultra-high Moveable Wall can be up to 16 meters, and the ultra-high movable partition wall brings a lot of convenience to people's work.
Specifications
Type | 65 type, 80 type, 100 type, ultra high 100 type. |
Finish | melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel |
Density | 28~32kg/m² |
STC | 40db-50db |
Dimensions | width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg |
Structure | 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing |
Panel Suspension | Top hunge system without the need for a floor track. |
Panel Width | Each panel 600mm-1200mm. |
Track | Aluminum OR Steel Track |
Roller on panel | Single or double roller. |
Panel Frames | Heavy-duty steel-gusseted aluminum inner frames reinforced with full height. |
Top&bottm seals | Top and bottom pressure retractable seals ensure effortless moved and locked. |
Module | 700mm - 1200mm maximum. |
Panel stacking | Numerous panel stacking options for complete flexibility. |
Panel face | MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc. |
Finishes | Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard |
Ultra high 100 type
Ultra-high Moveable Partition Wall is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high Moveable Partition Wall can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.
Features
Stacking Ways
Applications
The Movable Partition Wall divides a large space into various functional spaces that need to be used. The difference between the ultra-high movable partition partition and the ordinary movable partition partition is that the partition wall is heavier, and usually the super-large hotel is used for the partition. Building space for banquet halls and airports. Because of the large-scale acting, so you need to use your vision in style design. For better results, you can point out four suggestions:
1. Anti-personality
It must be consistent with the overall style of the hotel, and the hotel space must establish a prominent personality. By dynamically studying the differences, making full use of the personality and its cultural habits with different elements, the style will be changed. Hilarious and fun private cubicle.
2. Advocating nature
Social style protection, environmental protection at the same time, has become a consensus of consensus, and design activities at the same time show this broad attitude to the crowd from a wide range of people. Peace and coexistence.
3. People-oriented
When choosing the Movable Partition Wall of the hotel, it is necessary to use fresh wallpaper as a decorative surface or a glass partition with better light transmittance to adjust people's psychological depression, and adjust the mentality through the decoration of the movable partition through the indoor environment, so as to maintain a good attitude in this way. This is also the basic foothold for the hotel to adopt activity partitions.
4. Artistry and themes
The combination of the two is the guarantee of the quality of the hotel space. The theme of the hotel space decoration design should be able to combine both local themes and local historical and cultural characteristics. For example, local seaside features are used in the interior environment design and decoration of seaside hotels. The interior space can be designed with common decoration materials such as stone pillars and wooden houses. The eye-catching place is a welcome activity partition with a classical charm. You can also make full use of technology and waterproofing to find design ideas, but it must be consistent with the overall atmosphere of the hotel.
Product Categories : Movable Wall
