Model No.: MQ-PARTITION
Brand: MAGIC CUBE
Main Application: Commercial Furniture
Types Of: Office Furniture
Whether To Support Mail Order Packaging (special Packaging For Cross-border E-commerce): Y
Packaging: Carton Paper Packaging, MDF Batten Cover Corners
Productivity: 5000sq/Month
Transportation: Ocean
Place of Origin: China
Supply Ability: 5000sq/Month
Certificate: CE
HS Code: 76101000
Payment Type: T/T
Incoterm: FOB,CIF,EXW
Folding Partition Walls is a Movable Wall with general wall functions that can divide large space into small space or connect small space into large space at any time according to needs. It can play a role of multiple functions in one hall or one room. The Folding Partition Walls brings great convenience to people's work. For example, you can fold it on one side when you need it, so that the two spaces are temporarily joined to make them appear larger, which is convenient for temporary departmental meetings.
Specifications
Type | 65 type, 80 type, 100 type, ultra high 100 type. |
Finish | melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel |
Density | 28~32kg/m² |
STC | 40db-50db |
Dimensions | width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg |
Structure | 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing |
Panel Suspension | Top hunge system without the need for a floor track. |
Panel Width | Each panel 600mm-1200mm. |
Track | Aluminum OR Steel Track |
Roller on panel | Single or double roller. |
Panel Frames | Heavy-duty steel-gusseted aluminum inner frames reinforced with full height. |
Top&bottm seals | Top and bottom pressure retractable seals ensure effortless moved and locked. |
Module | 700mm - 1200mm maximum. |
Panel stacking | Numerous panel stacking options for complete flexibility. |
Panel face | MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc. |
Finishes | Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard |
Ultra high 100 type
Ultra-high detachable partition wall is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high partition can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.
Features
Stacking Ways
Applications
The commonly used hotel movable partitions have a high enough Sound Insulation coefficient, but in order to meet customers with stronger sound insulation effects, we need to strengthen the sound insulation materials when making partitions.
Ways to improve sound insulation
If a partition product wants to obtain high-quality Detachable Partition Wall, it cannot just focus on the improvement of thickness. Because it also needs to combine the density of the material, the sound absorption energy, the method of sound insulation treatment and the degree of fit. Mainly a few more points:
1. The material of the movable partition sound insulation cotton used in the hotel banquet hall needs to have strong sound absorption performance, moderate density, and absorb audio at the reflection angle to reduce the decibel effect;
2. The partition profiles must be precise in technology, horizontal and vertical, without special protrusions and asymmetry, to ensure that the movable partition can ensure the airtightness when combining partition walls, so as to achieve better noise reduction effect.
3. The material inside the movable clapboard is made of double-layer sound insulation cotton, which is a better sound insulation material, which can effectively isolate noises such as normal speech and humming.
4. The internal materials should be precisely matched, and the sound insulation material should preferably be taken from pure natural materials. Because it is a sealed space, more attention should be paid to the internal materials.
5. For those who need to pursue higher air tightness, in addition to the movable partition, it is necessary to set up soundproof curtains or other soundproof furniture;
6. The movable partition is not made of ordinary medium-density board, and needs to use sound-absorbing board or special flame-retardant cloth.
The reason for the aging of the partition
The Acoustic Folding Wall of the hotel banquet hall has the characteristics of strong sound insulation, fire prevention, portability and easy operation. This movable partition is especially suitable for space separation in hotel banquet halls, high-end office meeting rooms, high-end restaurant private rooms and other places. Most people will encounter the aging of movable partitions, but it is difficult to find the reasons. Let me introduce to you the reasons why movable partitions usually age:
1. Long-term use
All long-term exposure to the air and the influence of water, light and high and low temperatures will cause aging. Therefore, hotels should consider strong corrosion resistance and durability when selecting raw materials for partitions.
2. If the fabric of the hotel partition is a fabric curtain, it may be due to human factors or natural fading or discoloration may occur. Because of this, the hotel customer service staff must be careful maintenance of such fabric partitions. And maintenance.
3. The effect of damage
Because the Acoustic Folding Wall is very easy to be damaged in the process of pushing and pulling, if there is some water seepage in the hotel, the surface of the partition will also cause erosion.
Product Categories : Movable Wall
