Brand: MAGIC CUBE
Main Application: Commercial Furniture
Types Of: Office Furniture
Whether To Support Mail Order Packaging (special Packaging For Cross-border E-commerce): Y
Transportation: Ocean
Place of Origin: CHINA
Certificate: CE
HS Code: 76101000
Payment Type: T/T,Others
Incoterm: EXW,FOB,CIF
The doorfold partition wall that can be reasonably separated according to the space. It can be flexibly separated and combined according to the needs of different spaces, which greatly improves the utilization rate of the usable area. First, let's take a look at what is movable partition . The movable partition is also called a movable partition wall, a movable partition, and a high compartment. The movable partition is a new type of lightweight wall, which has the advantages of high strength, light weight, thermal insulation, Sound Insulation, fire and flame retardant, etc. Compared with ordinary partition walls, it can be customized in professional style, and it is light and easy to disassemble and move. Even one person can easily operate the movable partition wall, which can be retracted dexterously, which greatly facilitates human life. The simple and easy-to-operate wooden movable partition saves unnecessary time and labor costs.
| Type | 65 type, 80 type, 100 type, ultra high 100 type. |
| Finish | melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel |
| Density | 28~32kg/m² |
| STC | 40db-50db |
| Dimensions | width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg |
| Structure | 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing |
| Panel Suspension | Top hunge system without the need for a floor track. |
| Panel Width | Each panel 600mm-1200mm. |
| Track | Aluminum OR Steel Track |
| Roller on panel | Single or double roller. |
| Panel Frames | Heavy-duty steel-gusseted aluminum inner frames reinforced with full height. |
| Top&bottm seals | Top and bottom pressure retractable seals ensure effortless moved and locked. |
| Module | 700mm - 1200mm maximum. |
| Panel stacking | Numerous panel stacking options for complete flexibility. |
| Panel face | MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc. |
| Finishes | Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard |
Ultra high 100 type
Ultra-high Movable Partition is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high partition can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.
Features
Stacking Ways
Applications
Installation of doorfold partition wall 1. Before installing the wooden movable partition, check the track parts according to the drawings to assemble the track in order. 2. Mark the track lines and place the brackets at specific locations. 3. The installation of the movable partition wall track should be against the ceiling. 4. Repeatedly check whether the acoustic folding partition is still firmly fixed on the track. The rails and brackets only need to be stored loosely in the storage area, which makes it easier to move the brackets and plates to other places. Installation of acoustic folding partition matters 2 1. The movable partition door panel is hung on the track, and the escape exit track can be removed without rebuilding the crane. 2. The escape and exit tracks must be connected with special-made bracket tracks. 3. When installing the track, the construction can only be started according to the latest accurate data measured.
Product Categories : Moveable Divider Wall
