Movable sound proof foldable partition wall

$89.99 - 129.99 /Square Meter
Sound-absorbing board varieties:
Share:
  • Product Description
Overview
Product Attributes

Model No.MQ-PARTITION

BrandMAGIC CUBE

Main ApplicationCommercial Furniture

Types OfOffice Furniture

Whether To Support Mail Order Packaging (special Packaging For Cross-border E-commerce)Y

Supply Ability & Additional Information

PackagingCarton Paper Packaging, MDF Batten Cover Corners

Productivity5000sq/Month

TransportationOcean

Place of OriginChina

Supply Ability5000sq/Month

CertificateCE

HS Code76101000

Payment TypeT/T

IncotermFOB,CIF,EXW

Packaging & Delivery
Selling Units:
Square Meter
Package Type:
Carton Paper Packaging, MDF Batten Cover Corners
Product Description



  movable room dividers is a Movable Wall with general wall functions that can divide large space into small space or connect small space into large space at any time according to needs. It can play a role of multiple functions in one hall or one room. The movable room dividers brings great convenience to people's work. For example, you can fold it on one side when you need it, so that the two spaces are temporarily joined to make them appear larger, which is convenient for temporary departmental meetings.


Specifications

Type 65 type, 80 type, 100 type, ultra high 100 type.
Finish melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel
Density  28~32kg/m²
STC 40db-50db
Dimensions width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg
Structure 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing


Product Structure


The Most Popular Acoustic Folding Wooden Movable Divider Panels Movable Acoustic Wall Movable Walls
The Most Popular Acoustic Folding Wooden Movable Divider Panels Movable Acoustic Wall Movable Walls



Panel Suspension  Top hunge system without the need for a floor track.
Panel Width Each panel 600mm-1200mm.
Track Aluminum OR Steel Track
Roller on panel Single or double  roller.
Panel Frames  Heavy-duty steel-gusseted aluminum inner frames reinforced with  full height.
Top&bottm seals Top and bottom pressure retractable seals ensure effortless moved and locked.
Module 700mm - 1200mm maximum.
Panel stacking Numerous panel stacking options for complete flexibility.
Panel face  MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard




The Most Popular Acoustic Folding Wooden Movable Divider Panels Movable Acoustic Wall Movable Walls

Ultra high 100 type

     Ultra-high movable office partitions is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters movable office partitions can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.

Features

  • Load bearing of each meter is more than 2000 KGS
  • Each pulley bearing more than 1500 KGS
  • Easily moved even being pushed at waist-high
  • The panel can make a turn automatically as sliding in the straight rail


The Most Popular Acoustic Folding Wooden Movable Divider Panels Movable Acoustic Wall Movable Walls

The Most Popular Acoustic Folding Wooden Movable Divider Panels Movable Acoustic Wall Movable Walls

Stacking Ways

The Most Popular Acoustic Folding Wooden Movable Divider Panels Movable Acoustic Wall Movable WallsApplications

The Most Popular Acoustic Folding Wooden Movable Divider Panels Movable Acoustic Wall Movable Walls
The Most Popular Acoustic Folding Wooden Movable Divider Panels Movable Acoustic Wall Movable Walls
The Most Popular Acoustic Folding Wooden Movable Divider Panels Movable Acoustic Wall Movable Walls
The Most Popular Acoustic Folding Wooden Movable Divider Panels Movable Acoustic Wall Movable Walls


The Most Popular Acoustic Folding Wooden Movable Divider Panels Movable Acoustic Wall Movable Walls

The space design of the hotel can be roughly classified into functional spaces such as conference rooms and banquet halls according to its architectural layout, building area and space use. The difference in functional space creates the difference between them. As the most important space of the hotel, the banquet hall is more multi-functional.

We install foldable banquet movable room divider in the hall to meet the needs of various purposes of the banquet hall, so that we can more conveniently adjust the layout of the hall at any time according to customer needs. After the use of movable partition walls in the hotel banquet hall, the price of the banquet hall has continued to increase. The movable room divider of the hotel can change the size of the space at any time, because of this feature, it gives the diversification of the functions of the banquet hall. Because the banquet hall is equipped with this kind of movable partition wall, the space utilization efficiency will be higher than that of the same kind. This is because the hotel banquet hall event partition wall can give the banquet hall the ability to express its unique personality.

When installing the hotel movable partition, you only need to set the personalized rail guide system on the ceiling of the banquet hall in advance. When you need to change the size of the banquet hall, then place these hotel banquet hall partition walls along the movable partition. The rails are pushed, and once they're all put together and locked in place, you've got a small banquet hall. When you need a small box, push and pull these movable partition walls along the rail system of another "box-building", and after the same operation, it can become a smaller space. If you want to restore it to a large banquet hall later, you only need to stack the movable partition walls of these banquet halls.
